FRAMING SPECIFICATIONS
34 1/2"
(876 mm)
21 1/8 "
(537 mm)
14 7/8"
(32 mm)
5 1/8 "
(130 mm)
33 "
(838 mm)
2 1/4 "
(55 mm)
29 3/4 "
(754 mm)
32 "
(812 mm)
Front View
Top View
Right Side
Left Side
Electrical Access
13 3/4"
(350 mm)
5 1/4 "
(134 mm)
24 1/2"
( 622 mm )
27 1/2 "
( 700 mm )
21 1/8 "
(537 mm)
FIREPLACE SPECIFICATIONS
Front View
Side View
36 1/4 "
(921 mm)
25 5/8 "
35 1/4 "
(651 mm)
(895 mm)
51 1/4 "
(1302 mm)
32 "
(812 mm)
4 "
(102 mm)
15 1/8 "
(384 mm)
Corner View
Electrical
(left side)
Junction
Box
Electrical
Junction
Box
35 1/4 "
(895 mm)
Figure 2
Figure 3
Note: Framing dimensions are calculated for a nailing fl ange depth of 1/2"
