Place glass and cage on light kit,
install rubber washer and hex nut to
hold in place and tighten in direction
of arrow.
32
Install the 3 x 40 watt incandescent
candelabra bulbs.
31
Install finial cap nut and tighten in
direction of arrow.
33
Attach front cover to wall control
with screws provided.
37
Install wall control unit to outlet box
using machine screws provided.
36
To control fan speed select from High,
Medium or low speed buttons. To turn
the fan off press the Fan on / off button.
To dim lights press and hold button. To
turn off light press and quickly release
button.
Fan speed
control
buttons
Fan on / off
Light dimmer
for lights
38
Remove cover by snapping off from
top or bottom. Install 12V battery
into wall remote. Duracell
MN21/Eveready A23/GP 23A all 12V
34
Attach cover of remote by placing
over buttons and snapping into
place.
35
Reverse function for this fan is a
switch on top housing of the fan
body. Turn fan off and flip switch,
this will reverse the direction of the
blades.
39
