Miller Electric Spectrum 2050 - Manual

Comes Complete With:
ICE-55C hand-held torch with 25 ft
(7.6 m) or 50 ft (15.2 m) cable,
or ICE-55CM machine-held torch
with 50 ft (15.2 m) cable. Extra
consumables supplied
Heavy-duty work clamp with
25 ft (7.6 m) or 50 ft (15.2 m) cable
10 ft (3 m) power cord
Spectrum
®
2050
Air Plasma
Cutting and Gouging
Issued April 2008 • Index No. PC/7.0
The Power of Blue ® .
Miller Electric Mfg. Co.
An Illinois Tool Works Company
1635 West Spencer Street
Appleton, WI 54914 USA
Web Site
www.MillerWelds.com
International Headquarters
Phone: 920-735-4505
USA FAX: 920-735-4134
Canadian FAX: 920-735-4169
International FAX: 920-735-4125
The ICE-55C torch includes a drag
shield that attaches to the cup and
holds the tip 1/8 in (3.2 mm) off the
workpiece. This permits the operator to
drag the torch on the work piece while
cutting at full output, which increases
operator comfort and makes template
cutting easier.
Auto-Line ™ automatically links the
Spectrum ® 2050 to any primary input
voltage from 208 to 575 V, single- or
three-phase, 50 or 60 Hz.
A standard feature, the pilot arc
switch in expanded metal mode
allows operator to cut grates, chain
link fence, and other perforated
metals without retriggering the gun.
Consumables storage compartment
provides convenient access to
consumables and parts.
Can be powered by any Miller
engine drive with generator power
(e.g. Bobcat
™ ) or equivalent
competitive equipment. See page 3
for engine drive compatibility and
recommended settings.
Postflow cooling circuit cools
consumables and torch with postflow air
after you release the trigger. This feature
extends life of the torch and
consumables.
Starts without high-frequency so it
will not interfere with or damage
controls or computers.
Built-in gas/air filter/regulator is
housed inside the power source for
protection from transportation
damage. A standard air connection is
also provided on the back panel for
easy gas or air hookup.
Wind Tunnel Technology ™ prevents
abrasive dust and particles from
damaging internal components. Also, the
Fan-On-Demand
™ cooling system only
operates when needed. In dirty or dusty
environments, this feature reduces the
amount of airborne dust/dirt pulled
through the unit.
Portable, easy-to-carry unit weighs
only 86 lb (39 kg).
Power source is warranted for 3 years, parts and labor.
ICE torch is warranted for 1 year, parts and labor.
ICE-55C torch offers improved plasma
flow characteristics for increased
cutting speeds and longer consumable
set life.
Rated Output
55 A at 110 VDC,
60% Duty Cycle, 3-Phase
55 A at 110 VDC,
50% Duty Cycle, 1-Phase
Cutting Capability
Rated: 7/8 in (22.2 mm)
Sever: 1-1/8 in (28.6 mm)
Weight
With torch: 86 lb (39 kg)
Required Input
Pressure/Flow
6 SCFM (170 L/min) at
90 PSI MIN (621 kPa)
120 PSI MAX (828 kPa)
Industrial Applications
Construction
Maintenance/Repair
Fabrication
Processes
Air Plasma Cutting
and Gouging
Quick
Specs
Spectrum Plasma Cutters offer
reliability and performance that
others can’t match! See more at
MillerWelds.com/reliable
