37
4.1 Introduction
This chapter covers the loading of the software utility and then the
configuration of the unit from either a Windows based pc or a dumb
terminal. When a Windows based pc is used, the software utility is
loaded using the procedures in section 4.2 and then the unit is config-
ured using the procedures in section 4.3. If a dumb terminal is used, the
MulitFRAD 100 can be configured using the ASCII terminal menu
system present in memory of the unit.
4.2 Loading Software
1 Turn on your PC connected to the Data Port of your MultiFRAD
and run Windows®.
2 Create a backup copy of your MultiFRAD software diskette before
you install the software. Store the master diskette in a safe place
and install the MultiFRAD software using the backup copy.
3 Insert the backup disk for the MultiFRAD into the floppy drive.
4 Click on the File Menu in your Program Manager.
5 Click on Run. The Run dialog box is displayed.
6 Type a:\install or b:\install (depending on the location of your
floppy disk drive) in the Command Line field, and then click on
OK.
7 The MultiFRAD 100 - Select Directories dialog box is displayed.
If you are installing the software from drive A and your Destina-
tion Directory is the default directory, click on OK to continue
8 The Installing MultiFRAD dialog box is displayed.
