Middleby Cooking Systems Group PS360WB70-U - Manual (Page 9)

9
P360WB70
Europe
1a 1 2 31495 FLUE VENT SHROUD, 2" (51mm)
1b 1 2 32137 FLUE VENT SHROUD, 5"
(127mm)
2 1 2 30758 VENT MOUNTING BOX
3 1 2 27280-0005 NUT
4 2 4 21256-0008 HEX HEAD SCREW #10-32 X 3/8"
5 1 -- 30773 VENT, 14" (356mm) - FOR
LOWER OVENS
6 -- 1 30760 VENT, 50" (1270mm) - FOR
LOWER OVENS
7 1 1 30759 VENT, 29-1/2" (749mm) - FOR
UPPER OVENS
IV. SHROUDS AND VENTS
8 2 4 21292-0001 HEX HEAD SCREW #10-16 X 3/4"
9 1 2 35000-1017 UTILITY SHROUD HANGER
10 4 8 35000-1622 HANGER, REAR SHROUD
11a 1 2 30364 UTILITY SHROUD ASSEMBLY
11b 1 2 32049 UTILITY SHROUD ASSEMBLY
(Split Belt Conveyor)
12a 1 2 30363 UTILITY SHROUD, BOTTOM
12b 1 2 32048 UTILITY SHROUD, BOTTOM (Split
Belt Conveyor)
13 1 2 21416-0005 WASHER
14 1 2 2000346 SCREW 1/4"-20 X 1/2
QTY. QTY.
SINGLE DOUBLE
ITEM OVEN OVEN P/N DESCRIPTION
QTY. QTY.
SINGLE DOUBLE
ITEM OVEN OVEN P/N DESCRIPTION
