23
At a glance
Instrument cluster
Item Page
1 Coolant temperature
gauge
128
2 Fuel gauge with:
Fuel reserve warning lamp 294
3 L Left turn signal
indicator lamp
K Right turn signal
indicator lamp
46
4 Speedometer with:
v Electronic Stability
Program (ESP)
warning lamp
l Distance* warning
lamp 1
1 Vehicles without Distronic*: Warning lamp without
function. It illuminates with SmartKey in starter
switch position 2. It should go out when the engine
is running.
290
5 Tachometer 129
Item Page
6 Right display with:
- Antilock Brake Sys-
tem (ABS) malfunc-
tion indicator lamp
290
A High beam head-
lamp indicator
46
< Seat belt nonusage
warning lamp
289
7 J Reset button 127
8 Display with:
Program mode 164
Gear range
indicator 162
Digital clock (see
COMAND operat-
ing instructions)
9 Multifunction display
with:
Trip odometer 130
Main odometer 130
Stored speed for:
Cruise control
196
Distronic* 142
10 Outside temperature in-
dicator
129
11 Left display with:
1 Supplemental
restraint system
indicator lamp
292
; Brake warning
lamp, except
Canada
293
3 Brake warning
lamp, Canada only
293
? Engine malfunction
indicator lamp
294
12 Knob for instrument
cluster illumination
127
Item Page
