Electric Connection
3
Electric Connection
To main left
speaker
To
right
speaker
main
To rear left
speaker
To rear right
speaker
White/Black
White
Gray/Black
Gray
Green Black
/
Green
Purple/Black
Purple
Lgnition key
swtich
Car fuse box
(main fuse)
Battery
Connect control for antenna
or remote control for amplifier
(Blue)
ACC wire
(Red)
Battery wire (Yellow)
Car fuse box
Ground wire(Black)
(To car chassis)
CAR ANTENNA
MAIN LEFT RCA OUT
AUX LEFT IN
MAIN.L
MAIN.R
SURROUND
.
L
1
1
2
2
MAIN RIGHT RCA OUT
AUX RIGHT IN
VIDEO IN
TV ANTENNA PLUG
VIDEO OUT
SURROUND LEFT
SURROUND RIGHT
SUB
CENTER
Light wire(
)
Orange
SURROUND
.
R
CD CHANGE
