9
SA1532z SpeciFicAtiONS
Acoustic Performance
Frequency Range (–10 dB)
38 Hz–20 kHz
Frequency Response (–3 dB)
47 Hz–18 kHz
Horizonal Coverage Angle (–6 dB)
90º averaged 2 kHz to 10 kHz
Vertical Coverage Angle (–6 dB)
40º averaged 2 kHz to 10 kHz
Directivity Factor; DI (Q)
11.1 (12.9) averaged 2k Hz to 10 kHz
Max SPL long-term 135 dB @ 1m
Max SPL peak 138 dB @ 1m
Crossover Points 700 Hz, 3000 Hz
Input/Output
Input Type Female XLR Balanced/Unbalanced
Input Impedance 50 kohms balanced
Loop-Through Male XLR Balanced/Unbalanced
(parallel with input)
Level Control Rotating knob (–15 to +5 dB),
center detent at 0 dB
High-Frequency Section
Voice Coil Diameter 1.75 in/44 mm
Horn Exit Diameter 1.0 in/25 mm
Phase Plug 3-slot optimized geometry
Diaphragm Material Titanium
Magnet Material Neodymium
Mid-Frequency Section
Diameter 6.0 in/152 mm
Phase Plug Optimized geometry
Diaphragm Material Epoxy-reinforced cellulose
Magnet Material Neodymium
Low-Frequency Section
Number of Drivers 2
Woofer Diameter 15.0 in/381 mm
Voice Coil Diameter 3.0 in/75 mm
Diaphragm Material Epoxy-reinforced cellulose
Magnet Material Ferrite
Power Amplifiers
Low-Frequency Power Amplifier
Rated Power 1100 watts rms
Rated THD < 0.03%
Design Class G, Hybrid
Mid and High-Frequency Power Amplifiers
Rated Power 100 watts rms
Rated THD < 0.03%
Design Class AB
Line Input Power
US 120V, 60Hz
Recommended Amperage Service: 20 amps
Europe 230V, 50Hz
Recommended Amperage Service: 16 amps
AC Connector 3-pin IEC 250 VAC
Safety Features
Input Protection Low frequency dynamic bass
protection, rms limiting, power
supply and amplifier thermal
protection
Display LEDs Power ON, Signal Present, Limit,
Thermal (cool down auto-reset)
Construction Features
Basic Design Trapezoidal, 10º sides
Material 13-ply Baltic birch, resin end caps
Finish Wear-resistant textured black
PVC vinyl
Handles One on each side, one top, one bottom
Grille Perforated metal with weather-
resistant coating
Physical Properties
Height 50.0 in/127.0 cm
Front Width 19.1 in/48.5 cm
Rear Width 13.9 in/35.3 cm
Depth 18.1 in/46.0 cm
Weight 132 lb/60 kg
Mounting Methods Floor mount only.
The SA1532z should never be pole-mounted.
The cabinet has no rigging points and is not
suitable for flying. Never attempt to suspend the
cabinet by its handles.
Disclaimer
Since we are always striving to make our products better by in-
corporating new and improved materials, components, and manufac-
turing methods, we reserve the right to change these specifications
at any time without notice.
“Mackie” and the “Running Man” figure are registered trademarks
of LOUD Technologies Inc.
All other brand names mentioned are trademarks or registered
trademarks of their respective holders, and are hereby acknowledged.
©2004-2012 LOUD Technologies Inc.
All Rights Reserved.
