6.

Appendix


Console Port Pin Assignments

The female DB-9 serial port on the POE hub front panel is used to connect to the switch

for out-of-band console configuration. The web interface configuration program can be

accessed from PC running the system utility program. The pin assignments used to

connect to the serial port are provided in the following tables.

Figure 6-1. DB-9 Console Port Pin Numbers
