WXGA
WXGA
Full HD
Full HD Slim Bezel
Full HD
Full HD Slim Bezel
Full HD Slim Bezel
Quad HD
Model
LDT322V
LDT421V2
LDT422V
MDT421S
LDT461V2
MDT521S
MDT651S
56P-QF60LCU
Size
32”
42”
42”
42” Slim Bezel
46”
52” Slim Bezel
65” Slim Bezel
56”
Resolution
1366x768 (WXGA)
1366x768 (WXGA)
1920x1080 (Full HD)
1920x1080 (Full HD)
1920x1080 (Full HD)
1920x1080 (Full HD)
1920x1080 (Full HD)
3840x2160 (Super MVA LCD)
Format
16:9
16:9
16:9
16:9
16:9
16:9
16:9
16:9
Brightness
450cd/m
2
500cd/m
2
500cd/m
2
700cd/m
2
500cd/m
2
700cd/m
2
700cd/m
2
500cd/m
2
Weight (w/o stand)
14.5kg
26kg
21kg
23,5kg
33kg
40kg
46.5kg
51kg
Contrast Ratio
2500:1
1600:1
1300:1
1100:1
1500:1
2000:1
2500:1
1200:1
Technology
LCD
LCD
LCD
LCD
LCD
LCD
LCD
LCD
Speakers
7W+7W
7W+7W
7W+7W
7W+7W
7W+7W
7W+7W
7W+7W
No
Input / Output
Video Input
Composite
DVI-D
Composite
HDMI (PC/AV common)
Composite
HDMI, DVI-D (PC/AV common)
Composite
HDMI, DVI-D (PC/AV common)
Composite
AV common)
Composite
DVI-D (PC/AV common)
Composite
No
Audio Input
RCA (L/R) x2, Stereo Mini Jack x1
RCA (L/R) x2, Stereo Mini Jack x1
RCA (L/R) x2, Stereo Mini Jack x1, HDMI (digital audio)
RCA (L/R) x2, Stereo Mini Jack x1
RCA (L/R) x2, Stereo Mini Jack x1
RCA (L/R) x2, Stereo Mini Jack x1
RCA (L/R) x2, Stereo Mini Jack x1
No
RGB Input
BNC (R,G,B,H,V), Mini D-sub 15 pin, DVI-D (PC/AV common)
BNC (R,G,B,H,V), Mini D-sub 15 pin, HDMI (PC/AV common)
BNC (R,G,B,H,V), Mini D-sub 15 pin, HDMI, DVI-D (PC/AV
common)
BNC (R,G,B,H,V), Mini D-sub 15 pin, HDMI, DVI-D (PC/AV
common), DisplayPort
BNC (R,G,B,H,V), Mini D-sub 15 pin, HDMI (PC/AV common)
BNC (R,G,B,H,V), Mini D-sub 15 pin, HDMI, DVI-D (PC/AV common)
BNC(R,G,B,H,V), Mini D-sub 15Pin, HDMI, DVI-D (PC/AV common),
DisplayPort
DVI-D x4
Audio Output
RCA pin jack (L/R)
RCA pin jack (L/R)
RCA pin jack (L/R)
RCA pin jack (L/R)
RCA pin jack (L/R)
RCA pin jack (L/R)
RCA pin jack (L/R)
No
Communication
RS-232C (Mini D-sub 9 Pin) 1x in
RS-232C (Mini D-sub 9 Pin) 1x in
RS-232C (Mini D-sub 9 Pin) 1x in, 1x out
RS-232C (Mini D-sub 9 Pin) 1x in / 1x out
RS-232C (Mini D-sub 9 Pin) 1x in
RS-232C (Mini D-sub 9 Pin) 1x in / 1x out
RS-232C (Mini D-sub 9 Pin) 1x in / 1x out
RS-232C (Mini D-Sub 9 Pin), LAN RJ-45 x1
RGB Input Compatibility
640x480, 800x600, 1024x768, 1280x768,
1360x768, 1280x1024, 1600x1200* (*simpl.compression)
640x480, 800x600, 1024x768, 1280x768,
1360x768, 1280x1024, 1600x1200* (*simpl.compression)
640x480, 800x600, 1024x768, 1280x768, 1360x768,
1280x1024,
1600x1200*, 1920x1080, 1920x1200* (*simpl.compression)
640x480, 800x600, 1024x768, 1360x768, 1280x1024,
1600x1200*, 1920x1080, 1920x1200* (*simpl.compression)
640x480, 800x600, 1024x768, 1280x768, 1360x768, 1280x1024,
1600x1200*, 1920x1080, 1920x1200* (*simpl. compression)
640x480, 800x600, 1024x768, 1280x768, 1360x768, 1280x1024,
1600x1200*, 1920x1080, 1920x1200* (*simpl.compression)
640x480, 800x600, 1024x768, 1280x768, 1360x768, 180x1024,
1600x1200*, 1920x1080, 1920x1200* (* simpl.compression)
VGA, SVGA, XGA, WXGA, SXGA, UXGA, WUXGA, Quad HD
Signals Video Input
NTSC/NTSC4.43/PAL/ SECAM/PAL-60,
NTSC/NTSC4.43/PAL/ SECAM/PAL-60,
NTSC/NTSC4.43/PAL/ SECAM/PAL-60,
NTSC/NTSC4.43/PAL/ SECAM/PAL-60,
NTSC/NTSC4.43/PAL/ SECAM/PAL-60,
NTSC/NTSC4.43/PAL/ SECAM/PAL-60,
NTSC/NTSC4.43/PAL/ SECAM/PAL-60,
Digital RGB Video TMDS (DVI-D connector)
Signals Compatibility
Comp.:480i, 480p, 720p, 1080i, Digital: 480p, 720p
Comp.:480i, 480p, 720p, 1080i, Digital: 480p, 720p, 1080i
Comp/Digital.:480i, 480p, 576i, 576p, 720p, 1080i
Comp./Digital:480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Comp./Digital:480i, 480p, 720p, 1080i, 1080p
Comp./Digital:480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Componrnt:480i, 480p, 720p, 1080i, 1080p
No
Dimensions WxHxD mm (w/o stand)
789x476x133 mm
1022x612x127 mm
1023x614x133mm
966x559x116 mm
1122x663x136 mm
1202x698x122 mm
1498x873x139 mm
1333x872x420 mm
Standard Accessories
Power Cord, VGA cable,Cable Holder,
Remote Control, Clamper, Main Switch Cover,
User Manual
Power Cord, VGA cable, Cable Holder, Stand x2
Remote Control, Clamper x2, Main Switch Cover,
User Manual
Power Cord, VGA cable, Cable Holder, Stand x2
Remote Control, Clamper x2, Main Switch Cover,
User Manual
Power Cord, VGA cable,
Remote Control, Clamper x2
User Manual
Power Cord, VGA cable, Cable Holder, Stand x2
Remote Control, Clamper x2, Main Switch Cover,
User Manual
Power Cord, VGA cable,
Remote Control, Clamper x2
User Manual, CAT5 Tx Box, CD-rom
Power Cord, VGA cable,
Remote Control, Clamper x2
User Manual, CAT5 Tx Box, CD-rom
Power Cord,
Remote Control
User Manual, Desktop Stand
Optional Accessoiries
SP-321V (Speakers), ST-322V (Stand)
SP-421V (Speakers)
SP-421V (Speakers)
SP-421S (Speakers), ST-421S (Stand), DP-1CA5 (CAT5 kit),
OB-421S-AS (Silver bezel)
SP-461V Speakers
SP-521S (Speakers), ST-521S (Stand), OB-521S-AS (Silver Bezel)
SP-521S (Speakers)
No
Speaker Dimensions WxHxD mm
75x545.8x83 mm
95x612x72.1 mm
95x612x72.1 mm
95x612x72.1 mm
95x663x81.6 mm
80x698x72.1 mm
80x698x72.1 mm
No
Viewing Angle
Up and Down 178° / Left and Right 178°
Up and Down 178° / Left and Right 178°
Up and Down 178° / Left and Right 178°
Up and Down 178° / Left and Right 178°
Up and Down 178° / Left and Right 178°
Up and Down 178° / Left and Right 178°
Up and Down 178° / Left and Right 178°
Up and Down 176° / Left and Right 176°
Landscape Mode
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Portrait Mode
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
Face up Mode
No
No
No
No
No
Yes
Yes
No
Tiling Mode
Yes, up to 16 (4x4)
Yes, up to 16 (4x4)
Yes, up to 16 (4x4)
Yes, up to 25 (5x5)
Yes, up to 25 (5x5)
Yes, up to 25 (5x5)
Yes, up to 25 (5x5)
No
Warranty
3 years Return to base
3 years Return to base
3 years Return to base
3 years Return to base
3 years Return to base
3 years Return to base
3 years Return to base
3 years Return to base
Expected August 2010
