Portable WXGA Installation WXGA Installation WXGA Installation WXGA Installation WXGA Installation SXGA+ Portable Full HD Installation Full HD Installation WUXGA Home Cinema Home Cinema
WD620U WL2650U WD3300U WL6700U WD8200U MH2850U (Medical) FD630U FL6900U / FL7000U UD8400U HC3800 / HC3900 HC6800 / HC7000
Resolution 1280x800 (WXGA) 1280x800 (WXGA) 1280x800 (WXGA) 1366x800 (WXGA) 1280x800 (WXGA) 1400x1050 (SXGA+) 1920x1080 (Full HD) 1920x1080 (Full HD) 1920x1200 (WUXGA) 1920x1080 (Full HD) 1920x1080 (Full HD)
Format 16:10 (4:3 Zoom and Stretch Options
available)
16:10 (4:3 Zoom and Stretch Options
available)
16:10 (4:3 Zoom and Stretch Options
available)
16:10 (4:3 Zoom and Stretch Options
available)
16:10 (4:3 Zoom and Stretch Options
available)
5:4 (16:9 available) 16:9 (4:3 Zoom and Stretch Options available) 16:9 (4:3 Zoom and Stretch Options available) 16:10 (4:3 Zoom and Stretch Options available) 16:9 ( Zoom and Stretch Options available) 16:9 ( Zoom and Stretch Options available)
Brightness (ANSI Lumens) 4000 3500 4000 5000 6500 with Dual lamp 3100 4000 4000 / 5000 7000 with Dual lamp 1300 / 3000 1500 / 1000
Weight 3,6kg 4,7kg 10,5kg 9.8kg 16kg 4,9kg 3,6kg 9,8kg 16kg 3,5kg / 3,6kg 7,5kg
Contrast ratio 2000:1 600:1 2300:1 1000:1 2000:1 600:1 2000:1 1000:1 2000:1 3300:1 / 2000:1 30.000:1 / 72.000:1
Technology DMD 0.65” 3LCD 0.75” DMD 0.65” 3LCD 1,2” DMD 0.65” 3LCD 0,8” DMD 0.65” 3LCD 1.1” DMD 0.67” 0,65” DMD 3LCD 0.74”
Noise (*Low mode) 29dBA 29dBA 26dBA 29dBA 28dBa 29dBA 29dBA 29dBA 28dBa 25dBA 20dBA / 17dBA
Maximum Keystone Correction Vertical Auto Vertical +35°/-35° , Horizontal +25°/-25° Vertical +35°/-35° , Horizontal +25°/-25° Vertical +35°/-35° , Horizontal +25°/-25° Horizontal & Vertical Vertical +35°/-35° , Horizontal +25°/-25° Vertical Auto Vertical +13,5°/-14,5° Horizontal & Vertical Vertical +15°/-15° Vertical +15°/-15°
Frequency fh (kHz)
fv (Hz)
15-80
50-85
15-100
50-120
15-100
50-95
15-100
50-120
15-100
50-95
15-100
50-120
15-80
50-85
15-100
50-120
15-100
50-95
15-80
24-85
15-100
50-120
Lens Manual Manual Motorised Motorised Motorised Manual Manual Motorised Motorised Manual Motorised
Focal f=20,57~29,94mm f=24.0-29.0mm f=24.5-33.1mm f=51.0-64.0mm f=24.5-33.1 mm f=24,0~29,0mm f=20,57~29,94mm f=51.0-64.0mm f=24.5-33.1 mm f=20,6-30,1mm f=23,5-37,6mm
Speakers 10W mono 3W mono 10W mono 10W mono N/A 3W mono 10W mono 10W mono N/A No No
Input / Output
Video Input RCA x1, S-Video x1, HDMI x1 S-Video x1, RCA x1 HDMI x1 / S-Video x1 or BNC (Y,C) x1,
RCA x1 or BNC x1
S-Video x1 or BNC (Y,C) x1, RCA x1 or
BNC x1
BNC x1, S-Video x1, HDMI 1,3 x1 S-Video x1, RCA x1 RCA x1, S-Video x1, HDMI x1 S-Video x1 or BNC (Y,C) x1, RCA x1 or BNC x1 BNC x1, S-Video x1, HDMI 1,3 x1, SDI x1 HDMI (v.1.3) x1, RCA x1, S-Video x1 HDMI (v.1.3) x2, S-Video x1, RCA x1, RCA (Y,Cb,Cr) x1
Audio Input Stereo Mini Jack (3,5mm) x1, RCA Jack
(L/R) x1
Stereo Mini Jack (3,5mm) x2, RCA Jack
(L/R) x2
Stereo Mini Jack (3,5mm) x3, RCA Jack
(L/R) x2
Stereo Mini Jack (3,5mm) x2, RCA Jack
(L/R) x2
N/A Stereo Mini Jack (3,5mm) x2, RCA Jack
(L/R) x2
Stereo Mini Jack (3,5mm) x2, RCA Jack (L/R) x1 PC Stereo Mini Jack (3,5mm) x2, RCA Jack (L/R) x2 N/A No No
RGB Input Mini D-Sub 15 Pin x2 Mini D-Sub 15 Pin x2, DVI-D (HDCP) x1 Mini D-Sub 15 Pin x1, 5 BNC x1, DVI-D
(HDCP) x1
Mini D-Sub 15 Pin x1, 5 BNC x1, DVI-D
(HDCP) x1
5 BNC x1, Mini D-Sub 15 pin x1, DVI-D
x1
Mini D-Sub 15 Pin x2, DVI-D (HDCP) x1 Mini D-Sub 15 Pin x2 Mini D-Sub 15 Pin x2, 5 BNC x1, DVI-D (HDCP) x1 5 BNC x1, Mini D-Sub 15 pin x1, DVI-D x1 Mini D-Sub 15 Pin x1, Mini D-Sub 15 Pin x1
Audio Output Stereo Mini Jack (3,5mm) x1 Stereo Mini Jack (3,5mm) x1 Stereo Mini Jack (3,5mm) x1 (variable out) Stereo Mini Jack (3,5mm) x1 N/A Stereo Mini Jack (3,5mm) x1 Stereo Mini Jack (3,5mm) x1 Stereo Mini Jack (3,5mm) x1 N/A No No
RGB Output Mini D-Sub 15 Pin x1 Mini D-Sub 15 Pin x1 Mini D-Sub 15 Pin x1 Mini D-Sub 15 Pin x1 N/A Mini D-Sub 15 Pin x1 Mini D-Sub 15 Pin x1 Mini D-Sub 15 Pin x1 N/A No No
Communication RS232C (8 Pin), RJ-45 x1 RS232C (9 Pin), USB for Mouse, LAN
(RJ-45)
RS232C (9 Pin), USB for Mouse, LAN
(RJ-45), Wired remote
RS232C (9 Pin), USB for Mouse, LAN
(RJ-45), Wired remote
LAN (RJ-45) x1, RS-232C in/out x1,
Wired remote in/out x1
RS232C (9 Pin), USB for Mouse, LAN
(RJ-45)
RS232C (8 Pin), RJ-45 x1 RS232C (9 Pin), USB for Mouse, LAN (RJ-45), Wired
remote
LAN (RJ-45) x1, RS-232C in/out x1, Wired remote in/
out x1
RS232C (8 pin) RS232C (9 pin)
DC Ouput 5V (1,5A max) No No Yes No No No No No No 12V trigger out 12V trigger out
Input
RGB Input Compatibility 640x480 - 1280x800 - 1280x1024
comp.
640x480 - 1366x800 - 1600x1200
comp.
640x480 - 1280x800 - 1600x1200
comp.
640x480 - 1366x800 - 1600x1200
comp.
640x480 - 1280x800 - 1920x1200 comp. 640x480 - 1400x1050 - 1600x1200
comp.
640x480 - 1920x1080 - 1600x1200 comp. 640x480 - 1920x1080 - 1600x1200 comp. 640x480 - 1920x1200 640x480 - 1920x1080 - 1600x1200 comp. 640x480 - 1600x1200 comp.
Signals
Video Signals Input
Compatibility
NTSC/NTSC4.43/PAL (Including PAL-M,
N) / SECAM/PAL-60, Component
Video: 480i/p(525i/p), 576i/p (625i/p),
720p(750p), 1080i(1125i 60Hz),
1080i(1125i 50Hz)
NTSC/NTSC4.43/PAL (Including PAL-M,
N) / SECAM/PAL-60, Component
Video: 480i/p(525i/p), 576i/p (625i/p),
720p(750p), 1080i(1125i 50/60Hz),
1080p(11252p 50/60Hz), SCART (RGB
+1V Sync)
NTSC/NTSC4.43/PAL (Including PAL-M,
N) / SECAM/PAL-60, Component
Video: 480i/p(525i/p), 576i/p (625i/p),
720p(750p), 1080i(1125i 60Hz),
1080i(1125i 50Hz), SCART (RGB +1V
Sync)
NTSC/NTSC4.43/PAL (Including PAL-M,
N) / SECAM/PAL-60, Component
Video: 480i/p(525i/p), 576i/p (625i/p),
720p(750p), 1080i(1125i 50/60Hz),
1080p(1125 50/60Hz), SCART (RGB+1V
sync*)
NTSC/NTSC4.43/PAL (Including PAL-M,
N) / SECAM/PAL-60, Component
Video: 480i/p(525i/p), 576i/p (625i/p),
720p(750p), 1080i(1125i 50/60Hz),
1080p(1125p 50/60Hz), SCART (RGB
+1V Sync)
NTSC/NTSC4.43/PAL (Including PAL-M,
N) / SECAM/PAL-60, Component
Video: 480i/p(525i/p), 576i/p (625i/p),
720p(750p), 1080i(1125i 50/60Hz),
1080p(11252p 50/60Hz), SCART (RGB
+1V Sync)
NTSC/NTSC4.43/PAL (Including PAL-M, N) / SECAM/
PAL-60, Component Video: 480i/p(525i/p), 576i/p (625i/p),
720p(750p), 1080i(1125i 50/60Hz), 1080p
NTSC/NTSC4.43/PAL (Including PAL-M, N) / SECAM/
PAL-60, Component Video: 480i/p(525i/p), 576i/p
(625i/p), 720p(750p), 1080i(1125i 50/60Hz), 1080p(1125p
50/60Hz) (1080i(1250i 50Hz), SCART (RGB +1V Sync)
NTSC/NTSC4.43/PAL (Including PAL-M, N) / SECAM/
PAL-60, Component Video: 480i/p(525i/p), 576i/p
(625i/p), 720p(750p), 1080i(1125i 50/60Hz), 1080p(1125p
50/60Hz), SCART (RGB +1V Sync)
NTSC/NTSC4.43/PAL (Including PAL-M, N) / SECAM/
PAL-60, Component Video: 480i/p(525i/p), 576i/p (625i/p),
720p(750p), 1080i(1125i 50/60Hz), 1080p (24/50/60Hz),
NTSC/NTSC4.43/PAL (Including PAL-M, N) / SECAM/
PAL-60, Component Video: 480i/p(525i/p), 576i/p (625i/p),
720p(750p), 1080i(1125i 50/60Hz), 1080p (1125p
50/60Hz), 1080/24p, SCART (RGB +1V Sync)
Dimensions WxHxD (mm) 345x129x270mm 333x113x272 450x187x373 (excl. terminal cover) 443x207x434 490x200x420 (excl.cover) 333x113x272 345x129x270mm 443x207x434 490x200x420 (excl.cover) 345x129x270 427x159x440
Maximum Lamp Life (*Low Mode) 5000 hours 4000 hours 4000 hours 4000 hours 4000 hours Dual mode / 8000 hours
Single mode
5000 Hours 5000 hours 4000 hours 4000 hours Dual mode / 8000 hours Single mode 5000 hours 4000 / 5000 hours
Standard Accessoiries Power Cord, RGB Cable,
Remote Control, Soft Carry Case, Lens
cap, Lamp replacement tray
Manual on CD, Safety Manual, Quick
Start Guide
Power Cord, RGB Cable, AV Cable,
RS232C Cable, USB Cable,
Remote Control
Manual on CD, Safety Manual
Power Cord, RGB Cable, RS232C Cable,
Remote Control, Terminal Cover,
Manual on CD, Safety Manual, Quick
Start Card
Power Cord, RGB Cable, AV Cable,
RS232C Cable
Remote Control, Safety Pin x2, Terminal
Cover, Spare dust filter,
Manual on CD, Safety Manual
Power Cord, RGB Cable, RS232C Cable,
Remote Control, Terminal Cover,
Manual on CD, Safety Manual
Power Cord, RGB Cable, AV Cable,
RS232C Cable, USB Cable,
Remote Control
Manual on CD, Safety Manual
Power Cord, RGB Cable,
Remote Control, Soft Carry Case, Lens cap, Lamp
replacement tray
Manual on CD, Safety Manual, Quick Start Guide
Power Cord, RGB Cable, AV Cable, RS232C Cable,
Remote Control, Safety Pin, Filter, Terminal Cover,
Manual on CD, Safety Manual
Power Cord, RGB Cable, RS232C Cable,
Remote Control, Terminal Cover,
Manual on CD, Safety Manual
Power Cord, RGB Cable
Remote Control, Lens cap, Lamp replacement tray
Manual on CD, Eng. Paper manual, Safety Manual
Power Cord, RGB Cable, RS232C Cable,
Remote Control, Lens cap, Lamp replacement tray
Manual on CD, Safety Manual
Replacement lamp VLT-XD600LP VLT-XL650P VLT-XD3200LP VLT-XL6600LP VLT-XD8000LP VLT-XL650P VLT-XD600LP XLT-XL6600LP VLT-XD8000LP VLT-HC3800LP VLT-HC6800LP / VLT-HC7000LP
Optional Lenses No Yes, 3 Yes, 4 Yes, 4 Yes, 5 Yes, 3 No Yes, 4 Yes, 5 No No
Mechanical Lens Shift No No Yes Yes Yes No No Yes Yes No Yes
Virtual Lens Shift No No No No No No No No No No No
Instant Shutdown Yes No No No Yes No Yes No Yes Yes No
Diagnostic Function No Yes, via PJ Link Yes, via PJ Link Yes, via PJ Link Yes, via PJ Link Yes, via PJ Link No Yes, via PJ Link Yes, via PJ Link No No
Warranty Projector: 3 year, Lamp: 1 year or 500
hours use
Projector: 3 year, Lamp: 1 year or 500
hours use
Projector: 3 year, Lamp: 1 year or 500
hours use
Projector: 3 year, Lamp: 1 year or 500
hours use
Projector: 3 year, Lamp: 1 year or 500
hours use
Projector: 3 year, Lamp: 1 year or 500
hours use
Projector: 3 year, Lamp: 1 year or 500 hours use Projector: 3 year, Lamp: 1 year or 500 hours use Projector: 3 year, Lamp: 1 year or 500 hours use Projector: 3 year, Lamp: 1 year or 500 hours use Projector: 3 year, Lamp: 1 year or 500 hours use
Expected September 2010
