Blower housing – MTD E644E User Manual
Page 22
22
Blower Housing
REF.
NO.
PART
NO.
DESCRIPTION
1
712-0116
Lock Jam Nut 3/8-24
2
756-0178
Flat Idler
3
784-5632
Auger Idler Arm
4
710-0459A
Hex Cap Screw 3/8-24 x 1.50
5
741-0475
Bushing
6
736-0242
Bell Washer
7
712-3010
Hex Nut 5/16-18
8
712-0324
Hex Lock Nut 1/4-20
9
736-0463
Flat Washer
10
705-5226
Reinforcement Chute
11
731-1379
Chute Adapter
12
710-0134
Carriage Screw 1/4-20 x .62
13
710-0451
Carriage Bolt 5/16-18
14
738-0281
Shoulder Screw
15
736-0174
Wave Washer
16
712-3068
Hex Nut 5/16-18
17
732-0611
Extension Spring
18
736-0119
Lock Washer 5/16
19
05931
Bearing Housing
20
741-0309
Ball Bearing
21
684-0039B
24” Housing Assembly
684-0040B
26” Housing Assembly
684-0041B
28” Housing Assembly
22
736-0169
Lock Washer 3/8
23
712-0798
Hex Nut 3/8-16
24
784-5580
Slide Shoe
25
784-5581A
24” Shave Plate
784-5579A
26” Shave Plate
784-5575
30” Shave Plate
26
684-0065
Impeller Assembly
27
715-0114
Pin
28
618-0120
24” Gear Assembly
618-0121
26” Gear Assembly
618-0122
28” Gear Assembly
29
710-0604
Hex Washer Screw 5/16-18
30
784-5618
Bearing Housing
31
741-0245
Hex Flange Bearing
32
736-0188
Flat Washer
33
741-0493A
Flange Bushing
34
605-5188
Spiral 24” RH
605-5192
Spiral 26” RH
605-5196
Spiral 28” RH
35
605-5189
Spiral 24” LH
605-5193
Spiral 26” LH
605-5197
Spiral 28” LH
36
710-0890A
Shear Bolt 5/16-18 x 1.5
37
712-0429
Lock Nut 5/16-18
38
784-5647
Chute Crank Bracket
REF.
NO.
PART
NO.
DESCRIPTION
