Compensator Operation
3 Product Description
22 User Manual RKP-II (CA53461-001; Version 2, January 2010) © 2010 Moog GmbH
3.5.7 Servo Control, C1
Servo Control, C1
Fig. 11: Servo control, C1
Pos.
Description
Pos.
Description
1
Stroke ring
4
Adjustment lever for control shaft
2
Pilot spool
5
Control piston 1
3
Spool sleeve
6
Control piston 2
