24-frame/sec.
movie film signal
Conversion to
30-frame/sec.
with 2-3 pull-down
1 frame 1 frame 1 frame 1 frame 1 frame
New Color Wheel
Stopped down iris(4000:1) Fully open iris(2700:1)
Without 10-bit 3D Y/C separation With 10-bit 3D Y/C separation
2000:1 4000:1
Motor-driven variable lens aperture equipped, for optical
contrast adjustments that ensure optimal incident light
supply to the DMD chip. Two-level remote control switching
further streamlines use of selected brightness levels.
Further evolving the motor-driven iris lens with
2-level switching
New color wheel with true color reproduction
and handsome brightness
This projector features a DMD chip (wide panel) with
stellar 1024 576 dot resolution. Mirror inclination angle
of ±12 degrees effectively cuts black diffused light.
Besides this, the rear structure of the mirror uses dark
metal to block diffused reflection and stray light, setting
the scene for fine and rich gradation.
Dark chip 2-DMD, for high resolution of 1024 576
Movie film and other media recorded at 24 frames per
second are converted to 30-frame/sec. images, the same as
TV broadcasts. The bottom line is projection of high-detail
images closing in on the fine texture portrayed with film.
Mounted with 2-3 pull-down,
for classy reproduction of movie software
The digital trapezoidal distortion correction function
enables correction of picture distortion at ±20 steps.
Trapezoidal distortion correction
Image color and brightness signals are separated with
superb accuracy, using 3D processing. Cross color
(rainbow pattern noise) and dot interference (dotted
noise) are effectively curbed, while further use of the 10-
bit processing color decoder reproduces images with
even greater clarity.
Equipped with high picture quality reproduction circuit 3D Y/C separation, 10-bit color decoder
This projector produces outstanding brightness of 1000lm.
Even in living rooms or other brightly lit spaces,
comparatively flat video software or sporting events can
also be savored through top-quality images.
Top picture quality even in brightly light living
rooms, producing high luminance of 1000lm
Superb contrast to 4000:1
Equipped with an optical engine mounted with high-detail
all-glass lens, forging dramatic
improvements in contrast.
Motor-driven iris function lens
aperture further enhances the
package, elevating contrast to
the stellar level of 4000:1. All-Glass Lens
Note: Photo shows the
HC3000 remote control.
Note:Photo shows the HC3000.
25dBA low noise performance
Hushed low noise level of 25dBA realized with use of a low-noise fan,
color wheel holder configuration and lamp fin dimensions.
Center lens and front exhaust, for trouble-free installation and viewing
Adopted for redoubled ease in focusing the projected image at the center of the
screen is a center design that positions the lens at the center of the unit. And
with hot air released from the front-mounted exhaust port, there is no difficulty
in viewing from the side or behind the projector. < Digital Micro-Mirror Device >
< DMD Pixel Composition Map >
Torsion hinge
Yoke Landing chip
Mirror
White has been added to the conventional color wheel
(made up of six color parts), boosting brightness to an
outstanding 1000lm. A special
coating is also used to raise
the reproduction of reds - a
vital color group for the sake
of image reproduction.
Illuminated remote control, easy to use
in darker rooms too
The system includes an illuminated remote control
panel, with the buttons lighting up for easy use
even in darkened rooms. Picture quality is also
corrected also by remote, enabling direct operation.
