Installation Instructions Section 2
2-8
Connection to Ice Machine (cont.)
WATER INLET
VALVE
ACCESS
HOLE
SV1641G
WATER INLET
BARBED FITTING
WATER INLET
BARBED FITTING
Vinyl Tubing Installation
(Typical 22” Ice Machine Shown)
SV3064
IB600C IB800C IB1000C
ROUTE TUBING
ROUTE TUBING AND
CONNECT TO 90 ° ELBOW
SV1780 SV1770 RH WATER INLET
BARBED FITTING
QDUAL Q1400C
