USB-5201 User's Guide Specifications
27
USB specifications
Table 13. USB specifications
USB device type USB 2.0 (full-speed)
Device compatibility USB 1.1, USB 2.0
Self-powered, 500 mA consumption max
USB cable type A-B cable, UL type AWM 2527 or equivalent. (min 24 AWG VBUS/GND,
min 28 AWG D+/D-)
USB cable length 3 meters max.
Environmental
Table 14. Environmental specifications
Operating temperature range 0 to 70 ° C
Storage temperature range -40 to 85 ° C
Humidity 0 to 90% non-condensing
Mechanical
Table 15. Mechanical specifications
Dimensions 127 mm (L) x 88.9 mm (W) x 35.56 (H)
User connection length 3 meters max.
Screw terminal connector type and pin out
Table 16. Screw terminal connector specifications
Connector type Screw terminal
Wire gauge range 16 AWG to 30 AWG
