MAGPiX B350 - Manual (Page 12)

12
Viewfinding
•
The function of the binocular is as the viewfinder for the
binoculars.
•
The area seen through the binocular is a circular area,
approximately 8 times the magnification of original
image.
•
The MAGPiX B350 lens produces a 5 times enlarged
image with 4x3 standard shape.
Figure 17. View area difference between binocular and camera
•
You do not need to focus the binoculars for a focused
picture. The camera is auto-focus and is independent
from the binoculars.
Area Seen Through
Binocular
Area of Picture Taken
