Model DPC7310 DPC7311 DPC6410 DPC6411
Engine
Displacement
4.5 cu.in. / 73 cc. 4.5 cu.in. / 73 cc. 3.9 cu.in. / 64 cc. 3.9 cu.in. / 64 cc.
Maximum Power 5.6 HP / 4.2 kW 5.6 HP / 4.2 kW 4.4 HP / 3.2 kW 4.4 HP / 3.2 kW
No Load Speed 9,350 RPM 9,350 RPM 9,350 RPM 9,350 RPM
Max Spindle Speed 4,300 RPM 4,300 RPM 4,300 RPM 4,300 RPM
Max Cutting Depth 3-13/16'' (97 mm) 4-13/16'' (122 mm) 3-13/16'' (97 mm) 4-13/16'' (122 mm)
Fuel Tank Capacity 37 oz. 37 oz. 37 oz. 37 oz.
Fuel Mix 50:1 50:1 50:1 50:1
Arbor 20 mm 20 mm 20 mm 20 mm
Wheel Diameter 12'' (305 mm) 14'' (356 mm) 12'' (305 mm) 14'' (356 mm)
Net Weight 21.6 lbs. (9.8 kg) 22.0 lbs. (10.0 kg) 21.4 lbs. (9.7 kg) 21.8 lbs. (9.9 kg)
Shipping Weight 28.0 lbs. 28.0 lbs. 28.0 lbs. 28.0 lbs.
Master Carton Qty. 1 1 1 1
UPC Code 088381-06360-9 088381-06361-6 088381-06358-6 088381-06359-3
Specifications Specifications
Accessories Accessories
Features & Benefits Features & Benefits
■ 12'' Cut-off Wheel (965-210-621), Models DPC7310 & DPC6410
■ 14'' Cut-off Wheel (965-210-222), Models DPC7311 & DPC6411
■ Universal Wrench (941-719-140)
■ Torx Key (940-827-000)
■ Screwdriver (944-340-001)
■ Adapter Ring (22 mm to 1'') (394-228-120)
■ Dolly (DT2000)
■ Water Attachment Kit (394-365-600)
■ 1 Gallon Mix (2.6 oz.) 50:1 Fuel Mix (181115-A)
■ 2.5 Gallon Mix (6.4 oz.) 50:1 Fuel Mix (181114-A)
■ Assortment of 12'' & 14'' Diamond Blades
■ Assortment of 12'' & 14'' Cut-off Wheels
Standard Equipment Standard Equipment
■ Five-stage, foam-paper-nylon system with Advanced Directional Air Flow provides
very clean air for better saw performance
■ Reinforced aluminum blade guard with 70° range of limitless positioning using
a marked knob handle
■ Improved ignition system with larger flywheel and rare earth magnets for more power
■ Cutting arm position simply changes from center position to flush (outboard) position
allowing cuts directly adjacent to curb edges, walls or directly above the ground
■ Starter grip and decompression valve located on the same side for faster starting
■ On-Off-Choke operating switch on a single lever for operator convenience
■ Cushioned operator grips with 4 vibration-absorption rubber buffers for
increased operator comfort
■ Water kit is assembled to saw and can be used with garden hose, gravity tank
or pressure tank
■ Improved exhaust emissions are EPA Phase II compliant while maintaining power
and performance
All specifications subject to change without prior notice. All models and accessories subject to stock on hand.
NTF-0405 5M MA-0248-05 For more information, call 1-800-4MAKITA or visit
makitatools.com Makita U.S.A., 14930 Northam St., La Mirada, CA 90638
Models DPC7310/DPC7311/DPC6410/DPC6411
73 cc. & 64 cc. INDUSTRIAL POWER CUTTERS
Makita offers a wide variety of accessories for Power Cutters. For a complete listing, please
refer to the Makita General Catalog, or visit our website at makitatools.com, or call 1-800-4MAKITA.
Model DPC7311
Model DPC7310
Model DPC6411
Model DPC6410
Dolly (DT2000)
