Page 7 of 23
11/14/2006 Rev. 14
Table 2 Analog Outputs
Parameter
Name
Oxygen
Default
Possible
Options Possible
Ranges
OUTPUT 1
MODE O2
0–20.9%
4-20mA
O2, CARBON,
DEWPT, TEMP, LIN,
PROG O2 = 0 – 9999
%C = 0.00 – 2.55
DP = -99.9 – 212.0
Temp = -999 – 3000
LIN = -999 – 9999
PROG = 0 – 4095
OUTPUT 2
MODE TEMP
800-3000°F
4-20mA
O2, CARBON,
DEWPT, TEMP, LIN,
PROG O2 = 0 – 9999
%C = 0.00 – 2.55
DP = -99.9 – 212.0
Temp = -999 – 3000
LIN = -999 – 9999
PROG = 0 – 4095
NOTE: SEE PAGE 4 FOR TYPICAL CALIBRATION VALUES.
Calibration
The Smart Transmitter is factory calibrated. The calibration can be verified once a year or
according to customer calibration schedules. The instrument should be returned to the
factory if calibration is required.
