MAXX-2400HD Owner’s Manual Page 107
Gigabit Ethernet Indicators
The Gigabit Network Port card has the following indicator lights:
Label Indication Meaning
Green on The port is connected to a valid link partner
Green flashing Data activity
ACT/LNK
(Left)
Off No link
Off 10 Mb/sec
Green 100 Mb/sec
10=OFF
100=GREEN
1000=YELLOW
(Right)
Yellow 1000 Mb/sec
Access To Components
Be certain to shut down the server and disconnect the power cord before
opening the unit for service.
The following sections provide instruction on disassembly and re-assembly for maintenance.
Opening the Front Panel
The front panel is easily opened for access to the twelve disk drives, or for removing the server
from an equipment rack. Using a coin or a flat-blade screwdriver, unscrew the two large panel
fasteners on the left and right sides of the face panel. Pull outward and down to remove cover.
To re-install the front panel, verify that all wires are within the chassis, then place the front
panel into position and tighten the front panel access screws just enough to be snug.
Removing the Top Cover
Press down on the two latch buttons, slide the cover toward the rear of the chassis, then lift.
