AXP3/AXP4 Technical Specifications
Analog Audio Module
Audio channels
4 per video channel
Word Size
24-bit
Sampling Frequency
48 kHz
SNR
> 106 dB A-wtd. Ref to FS –1 dB
THD+N
< .01%
Input impedance
Z=10 k-ohm per leg
Output impedance
Z-50 ohm per leg
Headroom
20 dB above nominal +4 dBu operating level
Audio connector
XLR-3, gold plated
Data connection
68-pin x 1-meter cable connects AXP to MAXX-2400HD
Dimensions
3½” x 19” x 5¼“ [90 x 483 x 133mm] HWD.
Weight
8 lb [3.6 kg] net
Power
100 – 240 volts, 50/60 Hz, 50 watts
Power supplies
Modular, dual, redundant with separate IEC AC mains connectors
Cooling
Convection
Operating temperature
40º F to 85º F [4ºC to 29ºC]
Approvals
RoHS compliant
Country of manufacture
U.S.A.
