2
SECTION 1
DESCRIPTION
NOTE
Wiring Diagrams are contained in Section 6 of this Manual
and are also located inside inside the left side control box door.
Additional electrical information is provided on the oven's serial plate.
This Manual Must Be Kept For Future Reference.
PS724 SERIES OVEN SPECIFICATIONS
Conveyor Belt Width
18.00
″ (457 mm)
Heating Zone Length
24.00
″ (610 mm)
Baking Area Square Feet
3.0 sq. ft. (0.28 m
2
)
Overall Dimension – Standard Single Oven w/Legs - 8
″ Exit tray Installed
64.00
″ (1625 mm) L ×
36.00
″ (914 mm) W ×
43.69
″ (1110 mm) H ×
Overall Dimension – Double Oven
64.00
″ (1625 mm) L ×
36.00
″ (914 mm) W ×
64.00
″ (1625 mm) H ×
Overall Dimension – Triple Oven
64.00
″ (1626 mm) L ×
36.00
″ (914 mm) W ×
69.25
″ (1759 mm) H ×
Weight of Single Oven
250 lb (93.3 kg)
Shipping Weight
360 lb (163.3 kg)
Shipping Cube
61.1 ft
3
(1.73 m
3
)
Operating Range
17.4 kW/hr
Maximum Operating Temperature
600°F (316°C)
Warm-up Time
20 min.
Belt Speed Limits
0.30 - 12:00
SERIES PS724 ELECTRICAL SPECIFICATIONS
DOMESTIC OVENS
VOLTAGE
PHASE
HZ
kW
WIRING
BREAKER
POWER
POWER
SIZE
CORD
PLUG
SPECIFICATION
208
3
60
14.4 STD
4-WIRE / L1,L2,L3 & GROUND
50 A
8 GA, 4-WIRE
NEMA 15-50P
3
50-60
17.4 OPT
4-WIRE / L1,L2,L3 & GROUND
60 A
6 GA, 4-WIRE
NEMA 15-60P
240
3
60
14.4 STD
4-WIRE / L1,L2,L3 & GROUND
50 A
8 GA, 4-WIRE
NEMA 15-50P
3
60
17.4 OPT
4-WIRE / L1,L2,L3 & GROUND
60 A
6 GA, 4-WIRE
NS
480
3
60
17.4 STD
5-WIRE / L1,L2,L3,N & GROUND
30 A
8 GA, 5-WIRE
NS
INTERNATIONAL OVENS
VOLTAGE
PHASE
HZ
kW
WIRING
BREAKER
POWER
POWER
SIZE
CORD
PLUG
SPECIFICATION
208
3
50-60
17.4 OPT
4-WIRE / L1,L2,L3 & GROUND
60 A
6 GA, 4-WIRE - NS
NS
3
50-60
14.4 STD
4-WIRE / L1,L2,L3 & GROUND
50 A
8 GA, 4-WIRE - NS
NS
230-240
3
50-60
16 / 17.4 OPT
4-WIRE / L1,L2,L3 & GROUND
60 A
6 GA, 4-WIRE - NS
NS
3
50-60
13.2 / 14.4 STD
4-WIRE / L1,L2,L3 & GROUND
50 A
8 GA, 4-WIRE - NS
NS
380
3
50-60
17.4 STD
5-WIRE / L1,L2,L3,N & GROUND
40 A
10 GA, 4-WIRE - NS
NS
400-416
3
50-60
16.1 / 17.4 STD
5-WIRE / L1,L2,L3,N & GROUND
35 A
6 GA, 5-WIRE - NS
NS
STD = Standard
OPT = Optional
NS = Not Supplied
