Illustrated parts breakdown, Warning – Monessen Hearth VENT-FREE DIS33G User Manual
Page 38
38
23D8020
#1
#2
#4
#5
#3
#6
REPLACEMENT PARTS ARE AVAILABLE THROUGH YOUR RETAILER.
ILLUSTRATED PARTS BREAKDOWN
Failure to position the parts in accordance with these diagrams or failure to use only
parts specifi cally approved with this appliance may result in property damage or
personal injury.
W
ARNING
CHARRED TIMBER LOGS
Item
Description
Qty
CTCL18
1
Rear Log
1
70D0121
2
Right Base Log
1
70D0122
3
Left Front Base Log
1
70D0123
4
Right Front Log
1
70D0127
5
Left Top Log
1
70D0139
6
Right Top Log
1
70D0124
