LOCATION OF CONTROLS

2

11

15

14

12 13

20 21

22

161718 19

5

7

8

4

10

9

6

3

1

1. AC Power Jack (Rear of Unit)
2. Function Control
3. VOLUME Control
4. Carrying Handle
5. CD Compartment
6. AM/FM Dial Scale and Pointer
7. FM Rod Antenna
8. CD Door OPEN/CLOSE Area
9. TUNING Control
10. BAND Control
11. Speaker

12. POWER and PROG Indicators
13. Battery Compartment (Bottom of Unit)
14. STOP (■) Button
15. PROGRAM Button
16. REPEAT Button
17. Display
18. SKIP/Search

– /+ Button

19. PLAY/PAUSE and REPEAT Indicators
20. PLAY/PAUSE (Š/ ) Button
21. FM STEREO Indicator
22. Speaker
