4. Maintenance
Installation of the new battery module
Carry out the above operation in reverse order.
◗
Caution: risk of electric arc when connecting the battery.
◗
To maintain an identical level of performance and safety, use a battery module identical to that previously
mounted in the UPS.
◗
Press the two parts of the battery connector tightly together to ensure proper connection.
E - Remove the cover.
F - Remove the battery module by pulling
on the plastic tab and proceed with
replacement.
