Technical Data
Mitsubishi Electric, MA00816 11
3 Technical Data
Parameter E1032
Front panel, W x H x D 202 x 187 x 6 mm
Mounting depth
56.9 mm (156.9 mm including clearance)
Front panel seal IP 66
Rear panel seal IP 20
Keyboard material Membrane switch keyboard with metal domes. Overlay film
of Autotex F157 * with print on reverse side. 1 million
operations.
Reverse side material Powder-coated aluminum
Weight 0.875 kg
Serial port RS422/
RS485 25-pin D-sub contact, chassis-mounted female with
standard locking screws 4-40 UNC.
Serial port RS232C 9-pin D-sub contact, male with standard locking screws 4-40
UNC.
Ethernet Shielded RJ 45
USB Host type A (USB 1.1), max output current 500 mA
Flash memory for
application 12 MB (incl. fonts)
Real time clock ±20 PPM + error because of ambient temperature and supply
voltage.
Total max error: 1 min/month at 25
° C
Minimum life of the real time clock battery: 3 years
Temperature coefficient: 0.004 ppm/
° C 2
Power consumption at
rated voltage Normal: 0.15 A
Maximum: 0.35 A
Display FSTN-LCD. 240 x 64 pixels, monocrome transflective.
LED backlight lifetime at the ambient temperature of
+25
° C: >50,000 h.
Active area of display,
W x H 127.0 x 33.8 mm
Fuse Internal DC fuse, 2.0 AT, 5 x 20 mm
Power supply +24V DC (20 - 30V DC). 3-pin jack connection block.
CE: The power supply must conform with the requirements
for SELV or PELV according to IEC 950 or IEC 742.
UL: The power supply must conform with the requirements
for class II power supplies.
Ambient temperature Vertical installation: 0 ° to +50 ° C
Horizontal installation: 0 ° to +40 ° C
Storage temperature -20 ° to +70 ° C
Relative humidity 5 - 85 % non-condensed
EMC tests on the
operator terminal The operator terminal conforms with the essential protection
requirements in article 4 of the directive 89/336/EEC. Noise
tested according to EN61000-6-
3 emission and EN61000-6-2
immunity.
UL, cUL approvals
(when product or
packing is marked) UL 1604 Class I, Div 2 / UL 508 / UL 50 4x indoor use only
DNV Ceritfication in progress
NEMA 4x indoor use only
* See section Chemical Resistance for more information.
