REPLACEMENT PARTS
59
MH60/6N/6L
PUMP ASSEMBLY
Fig. 33 Part
Item No. No. Part Description Qty.
1 324580 Strainer ................................................................................................ 1
2 107966 Nut, Grip 10-32 w/Nylon Insert ........................................................ 1
3 104203 Clamp, Hose........................................................................................ 2
4 104165 Clamp, Hose........................................................................................ 1
5 107340 Clamp, Hose........................................................................................ 1
6 112383 Hose Pump, Discharge........................................................................ 1
7 109562 Hose, Suction ...................................................................................... 1
8 100734 Bolt 1/4-20 x 1/2" Hex Head .............................................................. 1
9 106482 Washer, Lock 1/4" Split ...................................................................... 1
10 110247 Nut, Hex Jam 7/16-20 ........................................................................ 1
11 110248 Washer, Flat ........................................................................................ 1
12 107463 Plug 1/4" ............................................................................................ 1
13 107137 Bolt 10-32 x 7/8 Hex Head ................................................................ 11
14 100194 Nut, Grip (10-32) (Not Shown) .......................................................... 11
15 0501505 Washer, Lock Int SST #8 .................................................................... 11
16 109651 Volute .................................................................................................. 1
17 113248 Impeller, SST ...................................................................................... 1
18 109653 Gasket, O-ring .................................................................................... 1
19 111111 Pump Seal .......................................................................................... 1
20 109649 Flange Assembly 1HP ........................................................................ 1
21 107690 Nut, Jam 3/8-16 .................................................................................. 4
22 106407 Washer, Lock 3/8" Split ...................................................................... 4
23 109648 Backing Plate ...................................................................................... 1
24 109654 Pump Slinger Washer.......................................................................... 1
25 110734 Stud 3/8-16 x 1-3/8 ............................................................................ 4
26 111145 Motor 1.4HP (208-240V/460V/60/3 .................................................. 1
26 111144 Motor 1.4HP (115V/208-240V/60/1) ................................................ 1
26 112163 Motor 1.4HP (115V/208-240V/50/1) ................................................ 1
26 0507708 Motor 1.4HP (575V/60/3) .................................................................. 1
27 100739 Bolt 5/16-18 x 3/4 Hex Head.............................................................. 4
28 102376 Washer, Flat 5/16 ................................................................................ 4
29 106013 Washer, Lock 5/16-18 SST ................................................................ 4
30 100142 Nut, Grip 5/16-18................................................................................ 4
31 100754 Screw, Flat 10-32 x 1/2 ...................................................................... 4
32 110270 Washer, Countersunk SST .................................................................. 4
— 109645 Kit, Pump (Includes 16, 18, 20, 23, 24) ............................................ 1
— 451643 Pump, Motor Assembly
Complete 1.4HP (208-240V/460V/60/3PH) ......................................
1
— 451642 Pump, Motor Assembly
Complete 1.4HP (115V/208-240V/60/1PH) ......................................
1
— 0707549 Pump, Motor Assembly
Complete 1.4HP (575V/60/3PH)........................................................
1
