REPLACEMENT PARTS
37
MH-60/6N/6L
DOOR HANDLE, SPRING ASSEMBLY, AND SAFETY SWITCH
Fig. 22 Part
Item No. No. Part Description Qty.
1 112723 Bolt 5/16-18 x 15 Hex Head .............................................................. 2
2 108066 Spring, Extension................................................................................ 2
3 107397 Block, Spring Hook ............................................................................ 2
4 0509166 Door Handle........................................................................................ 1
5 107437 Bolt M6 x 45MM Hex Head .............................................................. 4
6 107396 Block, Upper Pivot.............................................................................. 2
7 107393 Pin, Pivot ............................................................................................ 2
8 0508864 Handle, Grip........................................................................................ 2
9 107395 Block, Lower Pivot ............................................................................ 2
10 107420 Nut, Plain M6...................................................................................... 8
11 107436 Screw M6 x 16MM Filister ................................................................ 6
12 107399 Support, Pivot Block .......................................................................... 2
13 108368 Gasket, Backing .................................................................................. 2
14 304811 Plate, Backing .................................................................................... 2
15 100740 Bolt 5/16-18 x 1 Hex Head ................................................................ 2
16 107966 Nut, Grip 10-32 w/Nylon Insert ........................................................ 8
17 322077 Guard, Splash ...................................................................................... 2
18 100097 Screw 10-32 x 1/2 Truss Head............................................................ 8
19 0509264 Bushing, Side Door ............................................................................ 2
20 0509274 Nut, Acorn 5/16-18 SST .................................................................... 2
21 0309167 Lift Bar, Door...................................................................................... 2
22 102376 Washer, Flat ........................................................................................ 2
23 104002 Bolt 5/16-18 x 1-1/2............................................................................ 2
24 100154 Nut, Plain 5/16-18 .............................................................................. 4
25 106013 Washer, Lock 5/16 Split...................................................................... 2
26 102376 Washer 5/16 x 3/4 x 1/16 .................................................................... 4
27 321927 Spring Anchor Bracket........................................................................ 1
28 0509199 Switch, Door Safety............................................................................ 1
29 0309451 Bracket, Switch .................................................................................. 1
30 107967 Nut, Grip (1/4-20 w/Nylon Insert)...................................................... 2
