Makita HR4500C (MJ) - Manual (Page 3)

3 Model HR4500C
Item Part No.
No. No. Used Description
Item Part No.
No. No. Used Description
91 265701-9 1 Screw M6X14
92 417442-5 1 Side Grip Base 75
93 152554-4 1 Grip 36 Com.
94 516841-9 1 Armature Assy (Includes Item
97 & 98)
95 266046-8 2 Tapping Screw 5X50
96 526111-8 1 Field Assy (Includes 139 - 141)
97 681642-5 1 Insulation Washer
98 211088-7 1 Ball Bearing 6000DDW
99 417439-4 1 Baffle Plate
100 267025-9 1 Flat Washer 15
101 211238-4 1 Ball Bearing 6202LLU
102 213231-4 1 Oil Seal 15
103 331596-3 1 Sleeve 12
104 416284-4 1 Switch Lever
105 651922-3 1 Switch TG71B
106 416126-2 1 Lead Guide
107 417443-3 1 Handle Cover
108 265995-6 2 Tapping Screw 4X18
109 421583-1 1 Sponge Sheet
110 265995-6 2 Tapping Screw 4X18
111 687063-9 1 Strain Relief
112 682560-0 1 Cord Guard 10
113 664276-9 1 Cord with Plug 2P-16-5.0
114 266021-4 2 Tapping Screw 5X20
115 417444-1 1 Handle
116 416285-2 2 Acrylic Pin 5
117 911233-1 2 P.H. Screw M5X20
118 631434-2 1 Controller
119 417431-0 1 Fix Rod
120 240016-5 1 Fan 90
121 253165-9 1 Flat Washer 8
122 931403-6 1 Hex. Nut M8
123 417441-7 1 Rear Cover
124 266021-4 4 Tapping Screw 5X20
125 265995-6 2 Tapping Screw 4X18
126 416292-5 2 Brush Holder Cover
127 263002-9 2 Rubber Pin 4
128 643650-4 2 Brush Holder Cap 6.5-13.5
129 181048-2 2 A.C. Carbon Brush CB-155
(2pcs/Set)
130 819064-1 2 Makita Mark
132 183332-1 1 Motor Housing Set
(Includes 638062-4 -
Lead Wire Unit L2, 643653-8 -
Brush Holder 6.5-13.5, 643661-9 -
Brush Holder & Item 130)
133 152768-5 1 Side Handle Base 75 Com.
134 417002-3 1 Side Handle Cam
135 417002-3 1 Side Handle Cam
136 252640-2 1 Wing Nut M8
137 417003-1 1 Side Handle
138 265439-6 1 Hex. Bolt M8X150
139 654020-2 2 Garter Spring
140 654079-9 2 Insulated Receptacle DF1.25
141 654502-4 2 Connector P-2
142 632851-9 1 Lead Unit
Accessories
A01 181573-3 1 Grease Vessel
A02 181490-7 1 Hammer Grease
A03 421342-3 1 Dust Cup 5
421664-1 1 Dust Cup 9
A04 191686-A 1 Makita Safety Glasses
A06 - - - - - 1 Core Bit Adaptor
(See Catalogue for Details)
A07 - - - - - 1 SDS Max C.T. Bit
(See Catalogue for Details)
A08 - - - - - 1 Core Bits (See Catalogue for Details)
A09 - - - - - 1 Bull Point (See Catalogue for Details)
A10 - - - - - 1 Cold Chisel
See Catalogue for Details)
A11 - - - - - 1 Scaling Chisel
(See Catalogue for Details)
A12 - - - - - 1 Clay Spades
(See Catalogue for Details)
A13 - - - - - 1 Bushing Tool
(See Catalogue for Details)
A14 - - - - - 1 Rammer(See Catalogue for Details)
A15 134915-0 1 Side Handle Assy
(Includes Items 133 - 138)
A16 134916-8 1 Grip 36 Assy
(Includes Items 87 - 93 & A17)
A17 321248-4 1 Depth Gauge
A18 765009-6 1 Blow-Out Bulb
A19 824607-6 1 Plastic Carrying Case
(Includes Item A20)
A20 416401-6 2 Latch
