373 Technical data
Technical
data
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technical data
Model C 230 KOMPRESSOR (203.747) 1
Engine 111
Mode of operation 4-stroke engine, gasoline injection
No. of cylinders 4
Bore 3.58 in (90.90 mm)
Stroke 3.48 in (88.40 mm)
Total piston displacement 140.1 cu.in. (2295 cm 3 )
Compression ratio 9.0:1
Output acc. to SAE J 1349 192 hp/5500 rpm
(145 kW/5500 rpm)
Maximum torque acc. to SAE J 1349 207 ft.lb/2500 – 4800 rpm
(280 Nm /2500 – 4800 rpm)
Maximum engine speed 6200 rpm
Firing order 1-3-4-2
Poly-V-belt 1875 mm (routing I)
1355 mm (routing II)
1 The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corresponding data of all special bodies
and special equipment.
