Technical data, Fig. 3 – Miller Compass 20 User Manual
Page 5
4
Weight
2.7 kg (6.0 lb)
Payload Range
2.0 – 12.0 kg (4.4 - 26.5 lb)
Max. Capacity
20.0 kg (44.0 lb)
Tilt Drag
5 Selectable fluid drag positions + 0
Tilt Range
+ 90˚ / -75˚
Tilt Lock
Positive Lock caliper brake system
Pan Drag
5 Selectable fluid drag positions + 0
Pan Range
360˚
Pan Lock
Positive Lock caliper brake system
Counterbalance System
4 Selectable positions
(see performance graph)
Camera Platform Type
Quick release sliding platform
with 60 mm travel.
Camera Plate
Quick release mini euro camera plate
and 1/4”, 3/8” and 1/4” + Pin
Carriage
Mounting Base
Ø75 mm Ball Levelling
Ball Level Range
10˚
Handle
Standard black anodised pan handle
with adjustable angle.
Temperature range
-40˚ to +65˚ C (-40° to +149° F)
Construction
Lightweight diecast Aluminium alloy,
moulded reinforced plastics
Sealing
Water & Dust resistant
Finish
Matt black (low sheen) durable
powder coated with anti-corrosive
pre treatment
Warranty
3 Years.
Technical Data
Fig. 3
HEIGHT
ABOVE BOWL
