Makita AF502 User Manual
Page 2
2 Model AF502
Item
Part
No.
No.
No.
Used
Description
Item
Part
No.
No.
No.
Used Description
1
922127-5
4
Hex Socket Head Bolt M4x16
2
151430-9
1
Top Cap Com. Type 1(Green)
[Includes 421425-9 Top Cap Bumper
(Black)]
151508-8
1
Top Cap Com. Type 2 (Silver)
[Includes 421606-5 - Top Cap Bumper
(Green)]
3
421429-1
1
Cushion V
4
315448-6
1
Separator
5
213007-9
1
O Ring 8
6
231326-1
3
Compression Spring 6
7
213466-7
1
O Ring 35
8
315447-8
1
Head Valve
9
213466-7
1
O Ring 35
10
213413-8
1
O Ring 28
11
421551-4
1
Cushion “P”
12
213370-0
1
O Ring 22
13
150614-6
1
Driver Com.
14
415870-8
1
Collar
15
421807-5
1
Cylinder Separator(Old 421537-8)
16
343913-5
1
Backup Ring
17
331440-4
1
Cylinder
18
213461-7
1
O Ring 32
19
421791-4
1
Cushion F
20
232153-9
1
Leaf Spring
21
150578-4
1
Slide Door Com.
22
252140-2
1
Hex Lock Nut M3x5.5
23
267145-9
1
Flat Washer 3
24
233117-6
1
Compression Spring 6
25
256698-3
1
Pin 4
26
262054-7
1
Urethane Ring 3
27
311953-1
1
Lever
28
344152-0
5
Nail Guide
29
344235-6
1
Nail Stopper
30
262054-7
1
Urethane Ring 3
31
233114-2
1
Compression Spring 4
32
233114-2
1
Compression Spring 4
33
256697-5
1
Pin 4
34
344553-2
1
Pusher
35
233147-7
1
Compression Spring 4
36
233148-5
1
Compression Spring 6
37
266079-3
1
Hex Socket Head Bolt M4x14
38
344307-7
1
Spring Cover
39
922212-4
1
Hex Socket Head Bolt M5x12
40
922102-1
2
Hex Socket Head Bolt M4x6
41
344149-9
1
Joint
42
152505-7
1
Magazine Com.
43
322845-9
1
Pusher Guide
44
265422-3
2
Hex Socket Head Bolt M4x16
45
259009-1
1
Push Nut 3
46
150551-4
1
Contact Arm Com.
47
344301-9
1
Driver Guide
48
922107-1
2
Hex Socket Head Bolt M4x8
49
311994-7
1
Set Plate
50
257666-9
2
Sleeve 5
51
344153-8
1
Supporter
52
922242-5
2
Hex Socket Head Bolt M5x25
53
258023-4
1
Spring Pin 2.5-14
54
258010-3
1
Spring Pin 2.5-25
55
233120-7
1
Compression Spring 8
56
311951-5
1
Adjuster
57
311952-3
1
Stopper
58
233118-4
1
Compression Spring 4
59
165211-5
1
Link
60
256696-7
1
Pin 4
61
233119-2
1
Compression Spring 7
62
233114-2
1
Compression Spring 4
63
344150-4
1
Front Seal
64
261100-3
1
Rubber Washer
65
162173-8
1
Trigger Lock Pin
66
162174-6
1
Arm Lock Pin
67
258010-3
1
Spring Pin 2.5-25
68
258020-0
2
Spring Pin 2.5-22
70
442113-5
1
Top Cap Gasket
71
231309-1
2
Compression Spring 5
72
941001-8
2
Flat Washer 3
73
257903-1
2
Stop Ring E-2.3
74
213026-5
1
O Ring 7
75
331412-9
1
Joint Pipe
76
213026-5
1
O Ring 7
77
442111-9
1
Inlet Cap Gasket
78
413057-6
1
Inlet Filter
79
261094-2
1
Rubber Washer 8
80
316572-8
1
Inlet Cap Type 1 (Green)
317106-0
1
Inlet Cap Type 2 (Silver)
81
213488-7
1
O Ring 32 (Old 213459-4)
82
213223-3
1
O Ring 16
83
414999-7
1
Exhaust Cover
84
286219-7
1
Cap 12
86
922242-5
2
Hex Socket Head Bolt M5x25
87
415000-1
1
Hook
88
941102-2
1
Flat Washer 5(Old)
89
266100-8
1
Hex Socket Head Bolt M5x30
90
415593-8
1
Trigger
91
344148-1
1
Idler
92
415594-6
1
Trigger Valve Case
93
213218-6
1
O Ring 16
94
213034-6
1
O Ring 3
95
213034-6
1
O Ring 3
96
322773-8
1
Trigger Valve Stem
97
213028-1
1
O Ring 2
98
233121-5
1
Compression Spring 4
99
213030-4
1
O Ring 8
100
322775-4
1
Pilot Valve
101
159851-9
1
Housing Com. Type 1 (Green)
[Includes 421502-7 - Grip,
421500-1 - Bumper L (Black)
& 421501-9 - Bumper R (Black)]
159772-5
1
Housing Com. Type 2 (Silver)
[Includes 421502-7 - Grip,
421608-1 - Bumper L (Green)
& 421607-3 - Bumper R (Green)]
Accessories
A01
181434-7
1
Oil Supply 30cc
A02
783201-2
1
Hex Wrench 3
A03
421444-5
1
Nose Adaptor
A04
191686-A
1
Makita Safety Glasses
A05
192539-8
1
First Aid Kit
A06
824477-3
1
Plastic Carrying Case
(Includes Item A07)
A07
186347-7
2
Latch
