PAGE 22
INPUT FT.SW
CLEAN
PUSHED
MODERN
VINTAGE
POWER
ON ON
STANDBY
GAIN TREBLE MID PRESENCE BASS MASTER
SOLO OUTPUT
LEAD
RHYTHM
SLAVE
OUT
WARNING:
Unplug power
before replacing
fuse or removing
bolts mounting
chassis.
FU
SE
F US E
POWER FUSE
2.5 A
SLO
BLO 120 V~
50-60 Hz
2.5 A
10% 1 0 0%
FX MIX RETURN SEND
EFFECTS LOOP
WARNING : To reduce risk of fire or
electric shock, replace fuse with
same type and rating only. Do not
expose this unit to rain or moisture.
CAUTION : To reduce risk of fire or electric
shock, do not remove cover. No user-
serviceable parts inside. Refer
servicing to qualified personnel.
FRONT VIEW HEAD VERSION:
REAR VIEW HEAD VERSION:
BOTH SWITCHES
pt # 601073
LIGHT RECEPTACLE
pt # 703822
LIGHT BULB
pt # 703047
CONTROL
pt # 592148
KNOBS
pt # 408110
RED LENS
pt # 703782
SWITCHES
pt # 607101
CONTROL
pt # 592738
CONTROL
pt # 592737
CONTROL
pt # 592148
CONTROL
pt # 592378
CONTROL
pt # 592148
CONTROL
pt # 592792
CONTROL
pt # 592739
CONTROL
pt # 592150
CONTROL
pt #
592739
CONTROL
pt # 592737
CONTROL
pt # 592738
CONTROL
pt # 592794
JACK
pt # 610123
JACK
pt # 610120
ALL CONTROL KNOBS
Pt # 408110
AC RECEPTACLE
pt # 613713
FUSE
pt # 790347
JACK
pt # 618100
8 OHM 4 OHM 4 OHM
SPEAKERS
ALL 3 JACKS
pt # 618100
CONTROL
pt # 592736
JACKS
pt # 610111
SWITCHES
pt # 607101
RHYTHM
LEAD
SET TO RHYTHM
WHEN USING
FOOTSWITCH
SWITCH
pt # 602112
CONTROLS
pt # 591050
1
REVERB
2
RECT-O-VERB and
COMBO 50 ONLY
