(MENU)
TIMER
CAMERA
RECORD
ALARM
DWELL
PIP
DISPLAY
REMOTE
USER
SYSTEM
EVENT
16
EVENT
C1 VLOSS 26-DEC-2002 03:00:00
C2 ALARM 26-DEC-2002 03:00:00
K UNLOCKS 26-DEC-2002 03:00:00
M-HD ERR 26-DEC-2002 03:00:00
M-HD WARM 26-DEC-2002 03:00:00
PWR REST 26-DEC-2002 03:00:00
DMA ERROR 26-DEC-2002 03:00:00
M-HD REPL 26-DEC-2002 03:00:00
↑+↓: CLEAR
A single page can display 16 recorded events. Press “◄ ” or “► ” to change the
pages or press “▲ ” + “▼ ” to CLEAR the EVENT record.
DISK FULL: HDD is full
PWR REST : Power restored
M-HD REMS: HDD removal
M-HD REPL: HDD replace
M-HD ERR : HDD error
M-HD WARM: HDD warning
K UNLOCKS: Key is unlock
DMA ERROR: DMA error(Direct Memory Access)
C1 VLOSS : Video loss on Ch1
C2 ALARM : Channel 2 has been triggered by external I/O alarm
SYSTEM ERROR: System fail
POWER RESTORE : Power restored
VIDEO LOSS
Screen will display “VLOSS” in the center of display picture, if the video input is not connected properly.
SEARCH
1. LAST RECORD
Play the last recorded piece of video.
2. FULL LIST
List all recorded video on the HDD which sorted by time.
3. ALARM LIST
List all recorded video triggered by Alarm.
NOTE : If there are no Alarm in the record, the screen will
display “EMPTY”.
4. TIME SEARCH
Enter the specific time/date.
OPERATION OPTIONS
LAST RECORD
FULL LIST
ALARM LIST
TIME SEARCH
2003-JAN-01 01:02:03 M
2003-JAN-05 05:02:03 M
2003-MAR-12 04:02:03 M
2003-APR-02 03:02:04 M
2003-MAY-01 05:02:03 M
2003-AUG-09 01:02:01 M
← : PAGE UP → : PAGE DOWN
: Manual Recording
: Alarm Recording
: Timer Recording
M : Storage in Master HDD
S : Storage in Slave HDD
NOTE: It will display different color on each record list
mention above.
Advanced Operation
