(RECORD)
RECORD IPS 30
QUALITY NORMAL
RECORD MODE QUAD-FRAME
13
3. REC (RECORD)
Set up which channel you want to record.
ON : when alarm input is triggered, DVR will record alarming channel more frequently.
For example : when CH01 is triggered, the record method will become 1-2-1-3-1-4….
OFF : DVR will not record.
4. BR (BRIGHTNESS)
Adjust the brightness of each channel. The level is from 0 to 63.
5. CT (CONTRAST)
Adjust the contrast of each channel. The level is from 0 to 63.
6. CL (COLOR)
Adjust the color of each channel. The level is from 0 to 63.
7. HUE (HUE)
Adjust the hue of each channel. The level is from 0 to 63.
(MENU)
TIMER
CAMERA
RECORD
ALARM
DWELL
PIP
DISPLAY
REMOTE
USER
SYSTEM
EVENT
RECORD
1. RECORD IPS
Select the recording speed. The options are
as following :
NTSC－30、15、8、4、2、1
PAL－25、12、6、3、2、1
2. QUALITY
There are four quality settings : BEST, HIGH, NORMAL, BASIC.
NOTE : The relationship of Record time, IPS and Record quality,
please refer to page.22 Recording Speed.
3. RECORD MODE
There are three recording settings : QUAD-FRAME, QUAD-FIELD,
MULTIPLEX.
ALARM
1. ALARM ENABLE
Alarm will be triggered by event occurrence when the setting is
YES.
2. ALARM DURATION
Set the reaction time of the alarm mode responds to a buzzer.
Default setting is 10 Sec. Options are 10 Sec, 15 Sec, 20 Sec,
30 Sec, 1 MIN, 2 MIN, 3 MIN, 5 MIN, 10 MIN, 15 MIN, 30 MIN,
ALWAYS, AUTO.
NOTE : 1. Video loss, and Alarm messages will be shown the same as Alarm Duration time.
2. When the setting is AUTO, the alarm duration time is according to the setting of the
external alarm device.
3. During ALARM DURATION’S setting time, users can restart ALARM function by
pressing both “ENTER” + “STOP” buttons.
(MENU)
TIMER
CAMERA
RECORD
ALARM
DWELL
PIP
DISPLAY
REMOTE
USER
SYSTEM
EVENT
