CONTROL PANEL
No. Part No. Description
Section:
Series Qty
1 33002347 TIMER KNOB INSERT/CAP 10 1
2 22002997 PIN, LOCKING 10 1
3 22002996 KNOB, TIMER (GRY) 10 1
4 22003005 SKIRT, TIMER KNOB (BSQ) 10 1
5 22003006 SWITCH, (4 BUTTON TEMP) (BSQ) Note: BUTTONS 1&4 USE 22003875 BUTTONS 2&3 USE
22003876 10 1
6 22003860 SWITCH, PUSH BUTTON / BISQUE Note: BUTTONS 1&4 USE 22003876 BUTTONS 2&3 USE
22003875 10 1
7 22003865 CONTROL PANEL, FACIA - BSQ 10 1
8 33002327 CONSOLE (BSQ) Note: CONSOLE (BSQ) 10 1
- 22002925 SCREW Note: SCREW, CONSOLE BACK TO TOP 10 2
9 22002745 SWITCH, PRESSURE (BSQ) 10 1
- 22003461 PAD, PRESSURE SWITCH 10 1
10 22002711 SWITCH, 4 BUTTON OPTION / WHT Note: BUTTONS 1&4 USE 22001788 BUTTONS 2&3 USE
22001789 10 1
11 22003237 AIR DOME HOSE 10 1
- 903115 LOCK LIGHT 10 1
12 22001948 LENS, INDICATOR LIGHT 10 1
13 22003561 TIMER 10 1
14 22002529 CONSOLE BACK PANEL 10 1
- Y22002339 SCREW 10 1
15 22003003 BRACKET, ATC / TIMER 10 1
16 22002857 BOARD, CONTROL 10 1
2
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available
