Model TD090DW
Parts List
A = Standard Equipment
〇= Circuit Diagram
Fig.
Part No.
Description
Q'ty Unit
1 188519-0
HOUSING
SET
1
1
C10
810411-9
CAUTION LABEL
1
1
D10
INC.
31
0
2
865121-3
TD090D NAME PLATE
1
PC.
3
266130-9
TAPPING SCREW BIND PT 3X16
6
PC.
4 631813-4
LED
CIRCUIT
1
5
450504-6
F/R CHANGE LEVER
1
6 650599-1
SWITCH
C3HY-1A-LM
1
7 345998-7
SET
PLATE
2
8 643830-2
TERMINAL
1
9
231965-7
RING SPRING 10
1
PC.
10
267143-3
FLAT WASHER 11
1
PC.
11
233005-7
COMPRESSION SPRING 13
1
PC.
12 324711-6
BIT
SLEEVE
1
PC.
13 424109-8
BUMPER
1
14
158670-0
HAMMER CASE COMPLETE
1
15
261140-1
NYLON WASHER 20
1
16
216002-8
STEEL BALL 4.8
2
PC.
17 324895-0
ANVIL
M
1
18 324894-2
HAMMER
1
19
216019-1
STEEL BALL 3
24 PC.
20
267380-9
FLAT WASHER 20
1
21
234064-4
COMPRESSION SPRING 21
1
22 267813-4
WASHER
21
1
23
216019-1
STEEL BALL 3
2
PC.
24
227213-0
SPUR GEAR 17
2
25 324897-6
SPINDLE
1
26 268217-3
PIN
3.5
2
27
253052-2
FLAT WASHER 12
1
PC.
28
227215-6
INTERNAL GEAR 43
1
29
158671-8
BEARING BOX COMPLETE
1
29
C10
210112-3
BALL BEARING 6801LLB
1
29
C20
213188-9
O-RING 13
1
30 629851-8
DC
MOTOR
1
31 188519-0
HOUSING
SET
1
31
C10
810411-9
CAUTION LABEL
1
31
D10
INC.
1
0
A
A01 168467-9
HOLSTER
1
A
A02
DC10WA
DC10WA BATTERY CHARGER
1
A
A03
BL1013
BATTERY BL1013 SET
2
A
A04
784214-0A
#2 PHILLIPS BIT
1
A
A06
824842-6
PLASTIC CARRYING CASE
1
A06
C10
417724-5
LATCH
2
PC.
