Total Solutions for Industrial Device Networking
www.moxa.com e-mail: [email protected]
4-
Se
cu
re
T
er
m
in
al
S
er
ve
rs
/T
er
m
in
al
S
er
ve
rs
CN2510 Series
RJ4 RS- Port
Dimensions
(unit = mm)
Pin Assignment
4
19-inch Rackmount
The Rackmount Kit is a Standard Accessory
Serial Ports
8-pin RJ45, RS-232, 50 bps to 921.6 Kbps
Power Input
AC: 100 to 240 VAC input, 47 to 63 Hz
DC: ±48 VDC (38 to 72 VDC, -38 to -72 VDC)
LCM Display Panel
Reset Button
Push Buttons
LED Indicators
System Status, Serial Tx/Rx
Ethernet
RJ45 10/100 Mbps
Connection Cable
8-pin RJ45 to DB9 Cable
RS- Console Port
440 mm (17.3 in)
480 mm (19 in)
198 mm
(7.8 in)
45 mm
(1.77 in)
CN2510
Serial ports
Console
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
16 port R S-232 Async Server
Serial ports
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
LAN
Console
LAN
100-240 VAC
48 VDC
Pin
Signals
1
DSR (in)
2
RTS (out)
3
GND
4
TxD (out)
1
8
Pin
Signals
5
RxD (in)
6
DCD (in)
7
CTS (in)
8
DTR (out)
