95-6511 DASH DISASSEMBLY
13
DODGE RAM 1500 2009-11
DODGE RAM 2500/3500 2010-11
12V DC
A
B
C
P R N D
D
115V AC 150W
E
Disconnect the negative battery terminal
to prevent an accidental short circuit.
Remove (1) T25 Torx screw in the compart-
ment next to the cup holders. (Figure A)
1
2
4
Push down on the collar below the shifter
then pull the shifter straight up to remove.
(Figure D)
Continued on page 14.
Remove (2) Phillips screws in the pocket
below the climate control in the front of
the center console. (Figure B)
5
Unclip and remove the top of the center
console including the cup holders.
(Figure E) 6
Remove (2) 9/32” screws in the cup
holders. (Figure C)
3
