95-6511 DASH DISASSEMBLY
DODGE JOURNEY 2009-10
A
1 2 3 4 5 6 AUX AUX SET
VOLUME
PUSH ON PUSH AUDIO/SELECT AM
FM
DISC
LIST
MUSIC
TYPE
SEL;ECT TUNE/SCROLL
SEEK SEEK SCAN TIME INFO RW FF U
POWER
OUTLET
1 2 3 4 5 6 AUX AUX SET
VOLUME
PUSH ON PUSH AUDIO/SELECT AM
FM
DISC
LIST
MUSIC
TYPE
SEL;ECT TUNE/SCROLL
PUSH PUSH
OFF
PUSH
OUTLET
POWER
OUTLET
B
C
9
1
Remove (4) 7MM screws securing
radio to dash to remove. (Figure B)
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
3
NOTE: The top of the metal bracket in
the sub dash will need to be cut to
allow for the clearance of the Double
DIN radio’s chassis. (Figure C)
Unclip and remove the entire factory
radio trim panel including the a/c
controls. (Figure A)
TIP: Open the compartment door at the
top of the radio trim panel.
2
Continue to kit assembly.
