APPENDIX C: HMS-10 SPECIFICATIONS
22
HMS-10 COMPLIANCE
Output Power 300 W total
Note: Wattage rating based on the maximum unclipped burst sine-wave rms voltage the amplifier
will produce into the nominal load impedance.
THD, IM TIM <.02%
Load Capacity 4 : low channel, 12 : high channel
Cooling Convection
DC POWER
Voltage Requirement 48 V DC
Current Draw Note: At 48 V DC.
Idle Current 0.35 A rms
Maximum Long-Term
Continuous Current
2.03 A rms
Burst Current 3.31 A rms
Ultimate Short-Term
Peak Current
3.45 A peak
Inrush Current 4.55 A peak
PHYSICAL
Enclosure Multi-ply hardwood
Finish Black textured
Protective Grille Acoustically transparent, black cloth-covered frame
Mounting Fixed bracket or optional adjustable bracket with 13° downtilt and 5° uptilt
Dimensions 15.5” W x 19.5” H x 12.5” D without mounting bracket
(394 mm x 495 mm x 317 mm)
Weight 29.1 lbs (13.2 kg) with mounting bracket
ENVIRONMENTAL
Operating Temperature 0° C to +45° C
Non Operating Temperature <–40° C or >+75° C
Humidity To 95% at 35° C
Operating Altitude To 4600 m (15,000 ft)
Non operating Altitude To 95% at 35° C
Shock 30 g 11 msec half-sine on each of 6 sides
Vibration 10 Hz – 55 Hz (0.010 m peak-to-peak excursion)
HMS-10 Specifications
