Murphy Selectronic Tattletale ST Series - Manual (Page 5)

ST8F and ST10ASF
ST5ASF Gimbal Mounting (“G” Option)
2-7/8 in.
(73 mm)
Clearance
1-3/4 in.
(44 mm)
** Models ST10AS, ST5DAS, ST4x4, and ST8
* For model ST5AS
3-29/32 in.
(99 mm)
Gimbal
Mounting
Bracket
Annunciator
3-5/32 in. (80 mm) *
or
5-11/32 in. (136 mm) **
2-3/16 in.
(56 mm)
3-1/2 in.
(89 mm)
6-3/8 in.
(162 mm)
6-3/8 in.
(162 mm)
5-11/16 in.
(144 mm)
2-3/16 in.
(56 mm)
6-1/2 in.
(165 mm)
1-3/4 in.
(44 mm)
9-3/4 in.
(248 mm
DIMENSIONS
STA16
ST-95046B page 5 of 6
