4

ENGLISH

Explanation of general view

1

Switch trigger

2

Lock button

3

Lamp

4

Reversing switch

5

Action mode changing lever

6

Side grip

7

Chuck key

8

Sleeve

9

Ring

10

Retaining ring

11

Hexagonal nut

12

Wrench 19

13

Depth gauge

14

Grip base

15

Blow-out bulb

SPECIFICATIONS

• Due to our continuing program of research and devel-

opment, the specifications herein are subject to change
without notice.

• Note: Specifications may differ from country to country.

Intended use
The tool is intended for impact drilling in brick, concrete
and stone as well as for drilling without impact in wood,
metal, ceramic and plastic.

Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and can
only be operated on single-phase AC supply. They are
double-insulated in accordance with European Standard
and can, therefore, also be used from sockets without
earth wire.

Safety hints
For your own safety, please refer to the enclosed safety
instructions.

ADDITIONAL SAFETY RULES

ENB002-1

1.

Hold tools by insulated gripping surfaces when
performing an operation where the cutting tool
may contact hidden wiring or its own cord. Con-
tact with a “live” wire will make exposed metal
parts of the tool “live” and shock the operator.

2.

Always be sure you have a firm footing.
Be sure no one is below when using the tool in
high locations.

3.

Hold the tool firmly with both hands. Always use
the side grip.

4.

Keep hands away from moving parts.

5.

Do not leave the tool running. Operate the tool
only when hand-held.

6.

Do not touch the bit or the workpiece immedi-
ately after operation; they may be extremely hot
and could burn your skin.

SAVE THESE INSTRUCTIONS.

FUNCTIONAL DESCRIPTION

CAUTION:
• Always be sure that the tool is switched off and

unplugged before adjusting or checking function on the
tool.

Switch action (Fig. 1)

CAUTION:
• Before plugging in the tool, always check to see that

the switch trigger actuates properly and returns to the
“OFF” position when released.

To start the tool, simply pull the switch trigger. Tool speed
is increased by increasing pressure on the switch trigger.
Release the switch trigger to stop.
For continuous operation, pull the switch trigger and then
push in the lock button.
To stop the tool from the locked position, pull the switch
trigger fully, then release it.

Lighting up the lamps (Fig. 2)

For Model HP1620F, HP1621F

CAUTION:
• Do not look in the light or see the source of light

directly.

To turn on the lamp, pull the trigger. Release the trigger
to turn it off.

NOTE:
• Use a dry cloth to wipe the dirt off the lens of lamp. Be

careful not to scratch the lens of lamp, or it may lower
the illumination.

• Never use gasoline or thinner to clean the lens of the

lamp, or it will be damaged.

Model

HP1620/HP1620F/HP1621/HP1621F

Capacities

Concrete

16 mm

Steel

13 mm

Wood

30 mm

No load speed (min

–1

)

0 – 2,800

Blows per minute

0 – 44,800

Overall length

303 mm

Net weight

1.7 kg

Safety class

a

/II
