BBV, SBV Series Natural Vent Gas Fireplaces FIREPLACE DIMENSIONS & FRAMING
21”
(533 mm)
2156O”
(546 mm)
Min. Rough
Opening
Depth
4”
B-Vent
1/2” or 5/8”
Drywall
Spacers
40"
(1016 mm)
34”
(864 mm)
2156O”
(546 mm)
B
A
4056O”
(1029 mm)
Min. Rough
Opening
Height
1/2" or 5/8"
Drywall
Spacers
166M”
(426 mm)
756M”
(184 mm)
26QE”
(56 mm)
96 ”
(244 mm)
624037
400BBV dims
D - Min. Rough Opening Width
656O”
(165 mm)
13(6QE”
(341 mm)
C
E
F
G
G
6”
(152 mm)
Figure 3 -
SBV400, SBV500 Fireplace
Dimensions and Framing
Ref. SBV400 SBV500
A 40” (1016 mm) 46” (1168 mm)
B 36” (914 mm) 42” (1067 mm)
C 24ZC\zn” (630 mm) 30ZC\zn” (783 mm)
D 40Z\x” (1029 mm) 46Z\x” (1181 mm)
Framing Dimensions
E 67M\,” (1724 mm) 73M\,” (1876 mm)
F 34” (864 mm) 37” (940 mm)
G 48” (1219 mm) 52Z\v” (1327 mm)
For easier installation on SBV400 and SBV500
units, place gas supply pipe 6” to 8” inside
unit. Measure from the center of the gas
knock-out hole located at the bottom of the
left side.
NOTE
