Makita DA302D - Manual (Page 2)

2
SPECIFICATIONS
• Manufacturer reserves the right to change specifications without notice.
• Specifications may differ from country to country.
GENERAL SAFETY RULES
USA003-1
(FOR All BATTERY OPERATED TOOLS)
WARNING:
Read and understand all instructions. Failure to follow all
instructions listed below, may result in electric shock, fire and/or
serious personal injury.
Model DA302D DA392D DA312D
Capacities
Steel 10 mm (3/8”)
Wood 10 mm (3/8”) 12 mm (1/2”)
Wood screw 4.5 x 20 mm (3/16” x 3/4”)
No load speed (RPM) 0 - 800/min.
Overall length 296 mm (11-5/8”) 324 mm (12-3/4”) 324 mm (12-3/4”)
Net weight 1.1 kg (2.4 lbs) 1.3 kg (2.9 lbs) 1.4 kg (3.1 lbs)
Battery
Cartridge
Voltage Battery Charger Input Output Charging time
7000 7.2 V
DC9710
A. C. only
50 Hz - 60 Hz
D.C.7.2 V - 9.6 V
60 min.
9120
9.6 V
60 min.
9122
DC1414 D.C.7.2 V - 14.4 V
45 min.
9134 60 min.
9135 70 min.
1222
12 V
45 min.
1234 60 min.
1235 70 min.
