Martin Audio Touring and Theatre WT15 - Manual

W WT T1 15 5
Ultra-compact theatre enclosure
features
◗
Ultra-compact trapezoid enclosure
◗
ICT™ technology
◗
Vertical or horizontal orientation
◗
High SPL capability
applications
◗
Background music for clubs and bars
◗
Theatre delay/in-fill
◗
AV presentations
Century Point, Halifax Road, Cressex Business Park,
High Wycombe, Buckinghamshire HP12 3SL, England.
Telephone: +44 (0)1494 535312 Facsimile: +44 (0)1494 438669
E-mail: [email protected]
All information is Copyright © 2006 Martin Audio Ltd.
The ultra-compact WT15 is a trapezoid full-range speaker
capable of producing SPL’s associated with much larger
enclosures. It is designed specifically for theatre applications
where minimum size is a priority.
Only 11" high, it produces extended bandwidth and has high
output capability from twin 5" (125mm) drivers assembled in an
innovative two-way configuration utilising ICT™ technology. To
maximise output, the 5" (125mm) loudspeaker is augmented by
a second 5" (125mm) driver operating in tandem over the bass
and mid-range region. HF dispersion is identical in both
horizontal and vertical planes.
www.martin-audio.com
overall dimensions
technical specifications
TYPE Ultra-compact, two-way ICT™ trapezoid
FREQUENCY RESPONSE (5) 120Hz-20kHz ± 3dB
DRIVERS
5" (125mm) bass driver
5" (125mm) ICT™ driver
RATED POWER (2) 75W AES, 300W peak
RECOMMENDED AMPLIFIER 50-100W into 4 ohms
SENSITIVITY (6)
91dB
MAXIMUM SPL (7) 108dB continuous, 114dB peak
NOMINAL IMPEDANCE Externally switchable 4 or 16 ohms
DISPERSION (-6dB) 80º horizontal, 80º vertical
ENCLOSURE 5 litre, rear vented
FINISH Textured black paint
PROTECTIVE GRILLE Black perforated steel
CONNECTORS 2 x Neutrik NL4 switchable for
input +1,-1 or +2,-2
FITTINGS 2 x 3/8" flush mounted nut plates
on base and top
2 x M4 inserts for Omnimount 50
DIMENSIONS (W) 172mm x (H) 282mm x (D) 172mm
(W) 6.8ins x (H) 11ins x (D) 6.8ins
WEIGHT 5kg (11lbs)
touring and theatre
