Stone or marble countertops:
The steam deflector is not required for
countertops made of solid, waterproof
material. But it is needed for determin-
ing the correct position of the optic indi-
cator reflector.
^ Remove the black plastic reflector
holder from the steam deflector.
^ With the reflector cut out left and
frontward, align the steam deflector
with the front edge of the counter.
Trace the outline of the reflector onto
the underside of the counter with a
pencil.
Note:
For rounded countertops it may be nec-
essary to make the tracing closer to the
counter’s edge so the optic reflection
will be visible.
^ Adhere the double-sided sticker to
the back of the optic indicator reflec-
tor.
^ Remove the backing from the other
side of the sticker.
^ Line up the reflector with the tracing
and press into place.
The "Extended drying" feature can
be activated to further protect the
counter from condensation. See the
Operating instructions / Additional
features.
Installation
10
