Makita BTW120 - Manual (Page 2)

2
SPECIFICATIONS
• Manufacturer reserves the right to change specifications without notice.
• Specifications may differ from country to country.
GENERAL SAFETY RULES
USA003-1
(FOR All BATTERY OPERATED TOOLS)
WARNING:
Read and understand all instructions. Failure to follow all
instructions listed below, may result in electric shock, fire and/or
serious personal injury.
SAVE THESE INSTRUCTIONS
Work Area
1. Keep your work area clean and well lit.
Cluttered benches and dark areas invite acci-
dents.
2. Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases, or dust. Power
tools create sparks which may ignite the dust
or fumes.
Model BTW120
Capacities
Standard bolt M8 - M14 (5/16” - 9/16”)
High tensile bolt M6 - M12 (1/4” - 1/2”)
Square drive 12.7 mm (1/2”)
No load speed (RPM) 0 - 2,300/min.
Impacts per minute 0 - 3,000
Max. fastening torque 120 N.m (88 ft.lbs)
Overall length 176 mm (6-15/16”)
Net weight 1.5 kg (3.3 lbs)
Battery Cartridge Voltage Battery Charger Input Output Charging time
BH1220
12 V DC14SA
A. C. only
50 Hz - 60 Hz
D. C.
7.2 V - 14.4 V
30 min.
BH1233 50 min.
