4
99-7424 KIT ASSEMBLY
A
B
ISO MOUNT RADIO PROVISION WITH POCKET
Mount the ISO Brackets to the radio
using the screws supplied with the
radio. (Figure A) 1
Slide the radio into the radio housing
until it snaps into place. (Figure B) 2
Snap the Trim plate onto the front of
the Radio Housing. (Figure B) 3
Continue to final assembly.
* Note: Refer also to the instructions included with the aftermarket radio.
