Maxtor QUICKVIEW ATA - Manual (Page 31)

Product Specifications
4-2 Maxtor QuickView 400/500GB Serial ATA Hard Disk Drive
Performance Specifications
4.3 Physical Dimensions
Seek Times (typical read, ms)
Track-to-Track 0.8
Average (normal seek) ≤ 12
Full Stroke (normal seek) ≤ 17.0
Average Latency (ms) 4.17
Controller Overhead (ms) <0.5
Rotation Speed (RPM ±0.1%) 7217
Data Transfer Speed (MByte/sec max) SATA150 / 300
To/From Interface 115 MB per sec / 225 MB per sec
To/From Media (ID/OD up to nn.n, where
nn.n is the maximum transfer rate possi-
ble)
35 MB per sec / 68 MB per sec
Sustained (ID/OD up to nn.n, where nn.n
is the maximum transfer rate possible)
35 MB per sec / 68 MB per sec
Data Buffer Size (MB)/Type 16 MB
Drive Ready Time (typical sec) <15.0
PARAMETER VALUE
Height (maximum in mm) 26.30
Width (typical mm) 101.6
Depth (in. and mm) 147.0
Weight (maximum in grams) 718.0
